P47 SNAFU
HINGING THE RUDDER.
Glue the rudder hinges in place using
the same techniques used to hinge the ai-
lerons.
INSTALL THE AILERONS CONTROL
Fiberglass control horn
Aileron control horn.
6
HORN.
Epoxy.
Epoxy.
Instruction Manual.
INSTALL FLAP CONTROL HORN.
Install the flap control horn using the
same method as same as the aileron con-
trol horns.
Fiberglass control horn.
INSTALL ELEVATOR CONTROL HORN.
Fiberglass control horn.
.
Epoxy.
.
Epoxy.
