Summary of Contents for Pro-Line Boats 2010 29 Express
- Page 1 2010 Owner’s Manual Specifications subject to change without notice. Actual boats may vary from drawings and/or photos. Copyright 2005 Pro-Line Boats Inc., PO Box 1348, Crystal River, FL 34423 All rights reserved. April 2, 2009...
-
Page 3: Table Of Contents
Table of Contents Page Introduction ........................Specifications Dealer Responsibilities ...................... Customer Responsibilities ..........................................Owner’s Package ......................Yacht Certification Insurance and Registration ............................................Warranty Safety ......................Carbon Monoxide .............. Emergency Treatment for CO Poisoning Where CO May Accumulate ................. How To Protect Others and Yourself .............. - Page 4 Page Circuit Breakers ..................... Battery Charger ....................................Battery Switch for Dual Batteries ......Alternating Current and Direct Current Panels (AC/DC Panel) ..................Alternating Current (AC) Direct Current (DC) ....................Generator – 5.0 kw Gas (Optional) ......................................Blower ..................Shore Power with Cord .......................
- Page 5 Page Cabin Appliances and Accessories .................. Alcohol / Electric Stove ........................................Refrigerator .................... Microwave (Optional) ...... AM/FM Stereo with CD Player, Speakers and Remote (Optional) XM Stereo Upgrade (Optional) ................Upgraded Stereo Package (Optional) ..................Flat Screen Television with DVD Player and Cable Outlet (Optional) ................
- Page 6 Page Service and Care Fiberglass and Gelcoat ..................................Epoxy Barrier Coat and Bottom Paint ..........................Graphics ..................... Gunwale Trim / Rubrail Fuel Water Separators ...................... Water Pumps ................................................Compass ........................... Aluminum ........................Stainless Steel Corrosion Protection ......................Cabin / Companionway and Transom Doors ..............
-
Page 7: Introduction
Introduction Congratulations on the purchase of your new Pro-Line Boats 29 Express sport fishing boat. Welcome into the proud family of satisfied Pro-Line owners. Every expedition lets you enjoy the outstanding features designed into every boat we construct. Your new Pro-Line is more than just a boat, it's a whole new lifestyle. -
Page 8: Customer Responsibilities
The Pro-Line Boats Limited Warranty is attached to the warranty card. After signing the warranty card, your dealer will provide you with your copy of the warranty and mail the warranty card to Pro-Line Boats, Inc. A copy of the Pro-Line Boats Limited Warranty is also included in this chapter. - Page 9 When contacting Pro-Line Boats, please keep in mind that your issue will most likely be resolved at the dealership, using their facilities, equipment, personnel and/or sublet repair facilities. Note: There are items that are not covered by the Pro-Line Boats Limited Warranty, including but not limited to the following: ...
- Page 10 The Ten Year Limited Hull Structural Warranty is transferable to subsequent owners for a nominal fee. Please contact your dealer or Pro-Line Boats to obtain the applicable transfer form so that the new owner will have piece of mind knowing that their pre-owned boat comes with the same structural hull warranty protection that was...
-
Page 11: Safety
Safety Your Pro-Line boat has been constructed with safety in mind. But, remember, boating safety and the safety of your passengers is YOUR ultimate responsibility. You should fully understand the operations of your vessel as well as the basics in boating safety. Your local U.S. -
Page 12: Where Co May Accumulate
Shut off potential sources of CO, if possible. Correct ventilation problems and/or repair exhaust problems as appropriate. Investigate the source of CO and take corrective action, such as evacuating and ventilating the area, or shutting off the source of the CO, while at the same time evacuating and ventilating the area. -
Page 13: Fire
“teak” swim platform of a vessel while a wake builds up then lets go to body surf on the wave created by the boat; hence the term - Teak Surfing.) Teak surfing is never a safe activity. Never enter areas under swim platforms where exhaust outlets are located unless the area has been properly ventilated. -
Page 14: Hazardous Conditions
Be aware of and avoid conditions that can cause your boat to flood with water. Possible causes of flooding include: Damage to the hull or thru-hull fitting Waves washing into the boat Water entering cockpit due to improper loading ... -
Page 15: Alcohol
The United States Coast Guard Info Line (800)-368-5647 The USCG Headquarters by logging on to uscg.mil The information here is only a “brief” overview. Please contact the USCG for detailed information. Audible warning signals: One short horn blast: starboard course change. Two short horn blasts: port course change. -
Page 16: Controls
Controls Controls and engine systems vary greatly from one engine manufacturer to another. Please read your engine owner’s manual carefully. Note: If your engine package was not factory installed, some components that are normally standard installations may not be included. Throttle and Shift Controls for Twin Engines Ignition –... -
Page 17: Shift / Throttle / Trim
controls provide easier shift and throttle functions and little or no resistance. You may occasionally feel some friction at the binnacle but this can be adjusted at the binnacle per the instructions provided by the engine manufacturer. Shift / Throttle / Trim Your Pro-Line can be ordered with different shift/throttle systems based upon motor type. -
Page 18: Power Trim
Power Trim The power trim unit is located on the engine and can be operated by using the trim button on the engine or by using the trim toggle switch on the binnacle. To ensure the power trim is working, start by pressing the toggle trim switch in the up position and trim the engine to the full up position. -
Page 19: Trim Tab Indicators
While underway and in open water, clear of other boaters, depress the top half of the switches in half-second increments to achieve the desired degree of trim. To correct a starboard list, depress the top half of the port switch in small increments until the list is corrected. To avoid over trim, allow a few seconds between tab adjustments to allow the boat to respond. - Page 20 The increased maneuverability is a great asset when working a fish. The performance of a single- or multi-engine outboard can be enhanced when a thruster is installed, not only in terms of dockside maneuvering, but also when fighting fish. The bow thruster package includes either a joystick control or a touch pad control. To engage the thruster, press the on/off switch;...
-
Page 21: Systems And Accessories
Systems and Accessories Electrical System 110 Volt Outlets - GFI Protected There are 2 (two) 110 volt/ground fault interrupter (GFI) outlets installed in the cabin. One is located in the galley. The other is located on the starboard wall of the head and is protected by a plastic cover that lifts up for easy access. - Page 22 Baitwell Light - To activate the baitwell light, depress the switch to the up or forward position. This will activate the LED (light emitting diode) light inside your baitwell tub. It is a soft white light that will keep your bait moving and lively.
-
Page 23: Circuit Breakers
To activate either one of the pumps, depress the switch to the up or down position to activate the applicable pump. This action will drain the applicable fishbox of water and/or debris, grind up any debris and then discharge the water and/or debris overboard. When not in use, the switch should be left in the off or center position. -
Page 24: Battery Switch For Dual Batteries
Dynamic Thermal Output Control - Provides appropriate charging amps to your batteries while maintaining recommended charger temperature Has built-in protection for reverse polarity, ignition and temperature protection Battery Switch for Dual Batteries The battery switches are installed behind the hatch located below the transom sink at the port aft corner of the cockpit and are installed in close proximity to the circuit breakers. -
Page 25: Direct Current (Dc)
If the Polarity Light (red) comes on, you may have a problem with the shore power cable or your power source. Unplug the shore power immediately and do not use it until a qualified technician corrects this potentially dangerous situation. The AC volts and the AC amperes gauges allow you to monitor the AC power usage. - Page 26 Starting the Generator from the Main Unit - You can start the unit directly from the generator using the manufacturer’s instructions below:...
-
Page 27: Blower
Starting the Generator Remotely from the AC Panel - You can start the unit directly from the generator using the manufacturer’s instructions below: When you have finished using the generator, be sure to turn off the blower. Note: The manufacturer of the generator provides the limited warranty for the generator and most associated parts. -
Page 28: Shore Power With Cord
Blower Blower Switch Blower Exhaust Vent Shore Power with Cord Shore power is used for the operation of AC devices such as your air conditioner, battery charger, and 110 Volt outlets for other appliances. The shore power package includes a 25-foot long yellow shore power cord. The shore power outlet is located on the port wing, aft of the port light and next to the optional cable outlet. -
Page 29: Courtesy Light - Cabin
Switch the DC main and the cabin light switches to the on position to turn on the cabin lights. Each of these lights can then be turned on or off individually. When you are finished using the lights, press the cabin light and DC main switches to the off position. -
Page 30: Spreader Lights And Courtesy Light (Optional)
Spreader Lights and Courtesy Light (Optional) The installation of the spreader lights and Spreader lights Courtesy / Dome light the dome shaped courtesy light requires the optional hard top. The spreader lights are mounted to the aft side of the hard top frame, along the top edge. - Page 31 manufacturer’s owners manual). The air conditioning thru hull on the side of the boat will be releasing water to ensure that the air conditioner is running cool. Air conditioner return on face of Air conditioning vent in the Air conditioning vents in the the V berth storage area main salon mid berth cabin and head...
-
Page 32: Instrumentation
The seawater cooling system may develop an air lock at high speed or if the boat is removed from the water. An air lock will cause cooling water to fail to flow through the system. Open the strainer to purge air from the system and eliminate the air lock. -
Page 33: Compass
See the Safety section in this manual for more information. Avoid any horn use without an appropriate purpose. Additional information regarding audible warning signals should be covered in a safe boating course. Compass The compass is located on the dash on top of the console. To ensure that the compass light is working properly, press the Nav. -
Page 34: Fuel / Oil Systems
For example: If the fuel tank holds 200 gallons of fuel and you pumped 50 gallons of fuel into the tank, the fuel gauge should read approximately ¼ of a tank. This ensures that the fuel tank gauge and the fuel sender are working properly. If the fuel gauge is not reading correctly, we recommend that you have the fuel sender checked by your Pro-Line dealer’s Service Department or a qualified professional before considering changing out the gauge. -
Page 35: Fuel Water Separators
The fuel sender is equipped with a float that moves up and down with the fuel level in the tank. The fuel level information is sent to the fuel gauge and keeps you informed of the approximate fuel level in the tank. If you feel that your fuel gauge is reading incorrectly, before considering changing the gauge, have your Pro-Line dealer’s Service Department or a qualified service professional remove the fuel sender and check to make sure that the float is able to move up and down freely. -
Page 36: Fuel / Oil Leaks
maintenance of their product. When in doubt, always defer to the engine manufacturer’s instructions and/or recommendations. Fuel / Oil Leaks The fuel tank is vented overboard and the vent should be inspected for obstructions regularly. Ensure all of the fuel hoses remain properly secured and located according to NMMA standards. Inspect all hose clamps and fittings to ensure they are double clamped where needed and that there are no fuel leaks in any of the hoses. -
Page 37: Washdown Pump And Raw Water Washdown
Raw water washdown pump Washdown fitting Washdown Pump and Raw Water Washdown The washdown pump is mounted on the starboard aft stringer and is equipped with a pressure switch. This pump shares the same seacock with the baitwell pump and is accessible via the bilge hatch. The washdown fitting is mounted in the starboard aft corner of the cockpit. -
Page 38: Fish Boxes With Macerator Pumps
Forward bilge Bilge pump 2 pump with (high water pump) float switch Float switch is mounted aft of the port battery tray Bilge pump 1 with float switch Fish Boxes with Macerator Pumps Your boat is equipped with port and starboard fish boxes with a total capacity of 125 gallons. -
Page 39: Fresh Water Pump
Fresh Water Pump The 5.0 fresh water pump is accessible via the hatch under the mattress in the mid berth. Locate the fresh water pump switch (labeled fresh water) and the DC main switch on the AC/DC panel and move both switches to the on position. -
Page 40: Water Heater (Optional)
Water Heater (Optional) The optional 6-gallon capacity water heater is located in the cabin behind the galley area. It is best accessible by removing the refrigerator. To operate the water heater, locate the water heater and the AC main switches on the AC/DC panel and turn them both to the on position. Allow the water heater pump to operate for a couple of minutes then turn on the hot water faucet either in the galley or in the head to check the water temperature. -
Page 41: Overboard Discharge (Optional)
To operate or test the VacuFlush head system, make sure that your fresh water tank is full of water. Make sure that the DC main, fresh water, and head switches on the AC/DC panel are all in the on position. To flush the VacuFlush head system, use your foot to depress the pedal at the base of the head. -
Page 42: Alcohol / Electric Stove
Microwave Stereo - AM/FM CD with 4 speakers and remote Stereo - AM/FM CD with upgraded (4) speakers, woofer and amplifier Stereo - XM upgrade Television (flat screen) with DVD player and cable outlet Cabin floor –... -
Page 43: Refrigerator
Locate the alcohol dial on the front of the stove and turn it to the left to its highest setting. This also opens the chimney in the center of the stove. Apply a match or lighter to the chimney to light the stove. Then, adjust the dial to the desired setting. -
Page 44: Upgraded Stereo Package (Optional)
Upgraded Stereo Package (Optional) This upgraded stereo package adds the following electronics to the optional AM/FM stereo with CD player and remote: upgraded speakers, woofer and amplifier. This package also includes the upgraded satellite box shown at the right. This equipment is installed on the aft wall of the mid cabin. Flat Screen Television with DVD Player and Cable Outlet (Optional) The combined flat screen television and DVD player is mounted over the V berth... -
Page 45: Windows
Windows To allow for proper ventilation, 3 styles of windows have been installed throughout the cabin. Cabin Hatches - A cabin hatch complete with screen is installed in the ceiling of the main cabin. To open the window, remove the screen, turn both levers forward and push the hatch open to the desired position. -
Page 46: Hatches And Latches
Hatches and Latches Deck Hatches - The fiberglass deck hatches for the anchor locker, bilge and the 2 fish boxes can easily withstand the weight of passengers and gear; just like the rest of the deck surfaces. The hatches for the bilge and fish boxes are each equipped with gas shocks. -
Page 47: Transom Door
Transom Door The transom door is located on the starboard aft corner of the boat. The sliding bolt style latch secures the door in the closed position. To open the door, slide the latch starboard (to the left from inside the cockpit). The transom door should always remain closed while underway. -
Page 48: Thru Hull Fittings
stand on the bow rail or use it as leverage when pulling up an anchor, a fish or any other objects. Do not use the bow rail to tie off and/or secure a large catch, etc. Thru Hull Fittings Thru hull fittings provide overboard drainage. The following photos indicate the source of drainage for each of the thru hulls: Port Side Top Row / Left to Right... -
Page 49: Gunwale Trim / Rubrail
Gunwale Trim / Rubrail A white rigid vinyl gunwale trim with a stainless steel insert is installed at the juncture of the deck and hull. This durable trim provides a nice clean look and serves as somewhat of a cushion when you are docking, coming along side another vessel, etc. -
Page 50: Hard Top With Storage Box (Optional)
In addition to the standard seating, an optional port lounge seat with storage is available for installation. Hard Top with Storage Box (Optional) The anodized aluminum frame comes with a fiberglass hard top and built in storage box. A set of 4 rod holders is permanently mounted to the aft legs of the frame;... - Page 51 Patterns available for boats built in early model year 2009 are outfitted in your choice of Geometric Spice or Cosmic Caribbean. Cabin interiors for boats built later in the 2009 model year are outfitted in your choice of Kioske, Milky Way or Riddle.
-
Page 52: Countertops
Please see the Service and Care section of this manual for information on how to clean and care for your cabin cushions, pillows vinyl upholstery. Countertops The sinks and countertops in the galley and head areas are made of the same gelcoat covered fiberglass that is used in the construction of the deck and hull of the boat. -
Page 53: Wood Grain Cabinetry And Cabin Table
Wood Grain Cabinetry and Cabin Table The galley is outfitted with wood grain Formica cabinetry and a matching table. The table can be left in the raised position for dining or lowered to convert the area into sleeping quarters. To prepare the berth for sleeping, turn the knob on the table leg, push the table all the way down and then tighten the knob to secure the tabletop in position. -
Page 54: Operation And Performance
Operation and Performance Trim / Tilt The power trim system allows the operator to raise and lower the motor(s) throughout an infinite number of settings between its upper and lower limits. There is a trim setting that will yield maximum speed, stability or maneuverability for every throttle setting. -
Page 55: Starting
it may be desirable to re-prop your Pro-Line to enhance the desired performance needs for your area. For instance: Decreasing the pitch will enhance acceleration and power at high loads. Increasing the pitch will increase speed at light loads. ... -
Page 56: While Fueling
Close doors and hatches so fumes do not enter boat. Disembark all persons not necessary for the fueling operation. Prohibit all smoking and open flames on board and nearby. Have a fire extinguisher close by. While Fueling: ... -
Page 57: Service And Care
Service and Care To enjoy trouble free use of your Pro-Line, follow the recommended procedures and instructions relating to the service and care of your boat. Failure to follow proper maintenance practices will result in shorter life of your equipment and may void your warranty. Much of the installed equipment on your Pro-Line is warranted separately. -
Page 58: Graphics
This is done so that the epoxy coat will properly adhere to the hull, and when done correctly, will not void the hull warranty. Pro-Line Boats does not recommend using an etching primer in lieu of sanding the bottom. -
Page 59: Aluminum
dome. This will in no way affect the reading or accuracy. When restored to normal temperature, the air bubble will disappear. Clean the Lucite compass dome carefully with a moistened soft cloth to avoid scratching. In salt-water operation, salt crystals from the spray may form on the dome. These crystals should be removed with a moistened soft cloth. -
Page 60: Corrosion Protection
Always remove rust spots as soon as possible with a stainless, brass, silver or chrome cleaner. Irreversible pitting will develop under rust that remains on stainless for any period of time. Always use a cleaner, like a good car wax, for added beauty and protection. ... -
Page 61: Windshield
Bomar, A Division of Pompanette PO Box W, South East Street Charlestown, NH 03603 603-826-5792 Phone, 603-826-4125 FAX Windshield Care Instructions - Regular cleaning with fresh water and a soft cloth will keep and protect your windshield, window or hatch for years. ... -
Page 62: Isinglass
Four ounces (half cup) of chlorine bleach. Two ounces (one-fourth cup) of mild soap. One gallon of water. Clean with soft bristle brush. Allow mixture to soak for up to 20 minutes. Rinse thoroughly. ... -
Page 63: Cloth
For additional information regarding the care and maintenance of this product, please refer to the Morbern brochure provided in your owner’s package for recommended methods to clean specific types of stains. Cloth Cabin Cushions, Pillows and Curtains The manufacturer of the materials used in making the cabin cushions, pillows and curtains recommends the following cleaning procedures: Spot clean only with water based shampoo or foam upholstery cleaner. -
Page 64: Countertops
products such as Old English Furniture Polish, Liquid Gold, Pledge, Endust, etc. These products are all commercially available at most grocery stores, Home Depot, Lowes, etc. Countertops The sinks and countertops in the galley and head areas are made of the same gelcoat covered fiberglass that is used in the construction of the deck and hull of the boat. -
Page 65: Resealing
Flush water systems. Install hull drain plug. Verify operation of equipment before leaving dock. Resealing In the heat and sun, silicone and sealant can degrade over time. We recommend that you reseal around everything that comes in contact with the deck or hull with a high quality silicone such as 3M 5200 sealant annually. -
Page 66: Appendix
Appendix Helpful Check Lists Print and use these checklists, and do not operate your boat without doing the following: Each Time You Go On a Boat Trip Make sure you know where CO exhaust outlets are located on your vessel. ... -
Page 67: Boat Identification Information
Boat Identification Information Owner: Home Port: Dealer: Boat Name: Registration Number: Hull ID Number: Boat Model: LOA: Beam: Draft: Vertical Clearance: Hull: Deck: Interior: Warranty Registration Date: Fuel Capacity (Gallons): Ignition Key #: Cabin/Head Door Key #: Other Key #: Radio Call Letters: Bat.: Engine Make:... -
Page 68: Trouble Shooting Chart
Trouble Shooting Chart PROBLEM: POSSIBLE CAUSE Poor speed or fuel Wrong propeller for load or conditions. economy: Trim is in too far. Load is too far forward or too heavy. Boat has taken on water. Marine growth on hull. Line or anchor is dragging. Fuel is stale or partially blocked.
