Specifications - Altronix VertiLine8 Series Installation Manual

Altronix VertiLine CCTV Rack Mount Power Supplies provide 8 power outputs in a space saving 1U EIA 19" rack
mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC and/or
28VAC power outputs with surge suppression. VertiLine CCTV Rack Mount Power Supplies are also available in
sixteen (16) and twenty-four (24) output models with various power ratings.
Input:
• Selectable 115VAC, 60Hz or 240VAC, 50/60Hz input.
Output:
• Eight (8) individually selectable 24VAC or
28VAC fuse or PTC protected power outputs with
OFF position.
• Outputs are rated @ 3.5A (fused) or 2.5A (PTC).
• Surge suppression.
Features:
• Eight (8) power LEDs.
• Removable terminal blocks with locking
screw flange.
Eight (8) Output Rack Mount Configuration Reference Chart:
Altronix
Model
Number
24VAC or
VertiLine8
28VAC
24VAC or
VertiLine8D
28VAC
24VAC or
VertiLine83
28VAC
24VAC or
VertiLine83D
28VAC
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This
installation should be made by qualified service personnel and should conform to the National Electrical
Code and all local codes.
- 2 -
Overview:

Specifications:

5A 8 –
P
5A 8 –
P
10A 8 –
P
10A 8 –
P
Features (cont'd):
• Illuminated master power disconnect circuit
breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19" rack mount chassis
• Enclosure Dimensions (H x W x D approx.):
1.625" x 19.125" x 8.5"
(41.3mm x 486mm x 216mm).
3A 3A
10A 1.5A 0.8A
2.5A –
3A 3A
15A 3A
2.5A –
UL Listed for
Commercial
1.5A
VertiLine8 Series Installation Guide
UL 2044
CCTV
Equipment.
