System Control
System Control
■
Status LED
CAMERA
Camera Mode Display
STATUS
Displays power ON, fail status
ETHERNET
Displays
Ethernet
connection
status
Orange：
REC mode (during camera image memory recording
after camera image output and trigger detection)
Blue：
STOP/READY mode (memory image output. Playback
or transmission mode immediately after startup)
White：
VIEW mode (keeps the camera image output and
contents recorded in the memory)
Magenta：
ARM mode (deletes the camera image output and
contents recorded in the memory and records the
camera image in the memory)
Not lit：
Power OFF or starting up
Flashing：
Set to the EST mode and EST pulses are being input.
Only for VIEW, ARM, REC modes.
Lit green：
Power ON, normal state
Lit red：
Power ON, fail status (when camera starting up,
malfunction detected, abnormal power voltage
detected, rise in sensor temperature detected, or
abnormal settings detected)
Not lit：
Power OFF
Lit green：
Network connected
Flashing green：
Communicating with network
Lit orange：
Linking with 1000BASE-T
Not lit：
Network not connected or power OFF
※ If transmitting by linking with 1000BASE-T, the orange is lit and
the same LED flashes green, but the flashing green is darker than the
lit orange so it is difficult to see.
4-14
(00375)
