Recorder
■ Live Image Output
Output Method
Refresh Rate
■Recording Conditions
Recording Start Conditions
Recording End Conditions
■ Recording Trigger Mode
Normal Trigger
■

Trigger Timing

START
CENTER
END
CUSTOM
PC live output with Ethernet GigE Vison
Raw data of images the PC receives from MEMRECAM is converted to
images for display
Depends on the network status between the MEMRECAM and the PC as
well as the recording resolution
・About 5 frames/sec
・About 20 frames/sec
ARM Command (ARM from HXLink or such)
Recording Trigger Vibration (IF connector TRIG IB)
REC Command (REC from HXLink or such)
Normal recording trigger
The trigger point is about 5% before the beginning of the recording
memory
The trigger point is the center of the recording memory (About 50％)
The trigger point is about 5% before the end of the recording memory
The trigger point is at a preset value (-100～100%) , set at 1%
intervals
4-12
When the display resolution is1280x1024
When the display resolution is 680x480
