■Frame Rates MEMRECAM Q1m
Preset Frame Rates
■ Frame Rates and Valid Pixels MEMRECAM Q1m
Preset
Maximum Frame
Rate
Horizontal
Frames/Sec
2,000 or less 1280
At 2,500 1024
At 2,800 1280
At 3,000 768
At 4,000 640
At 5,000 512
At 6,000 384
At 8,000 320
At 9,000 256
At 10,000 192
At 20,000 160
At 30,000 64
At 40,000 64
At 50,000 64
At 87,000 64
(00375)
50, 60, 100, 250, 500, 1,000, 2,000, 2,500, 2,800, 3,000, 4,000,
5,000, 6,000, 8,000, 9,000, 10,000, 20,000, 30,000, 40,000, 50,000,
87,000 frames/sec
Maximum Frame Rate and Valid Pixels (Area)
Valid Pixels Horizontal-Vertical
Vertical
1024 Full SXGA
768 XGA 4:3
720 HDTV720 16:9
576 Split 4:3
480 VGA 4:3
384 Split 4:3
288 Split 4:3
240 QVGA 4:3
192 Split 4:3
144 Split 4:3
80 Split
48 Split 4:3
32 Split
16 Split
4 Split
4-3
Valid Image Area (mm)
Ratio
Horizontal
(Size)
7.17
5.73
7.17
4.30
3.58
2.87
2.15
1.79
1.43
1.08
0.9
0.36
0.36
0.36
0.36
Image Sensor
Vertical
5.73
4.30
4.03
3.23
2.69
2.15
1.61
1.34
1.08
0.81
0.45
0.27
0.18
0.09
0.02
