Pin Arrangement
Pin
Name
No.
1 MDI 0+
2 MDI 0-
3 MDI 1+
4 MDI
5 MDI 2+
6 MDI
7 MDI 3+
8 MDI
9 SYNC IN
10 SYNC IN RTN
11 DC IN
12 DC IN RTN
13 TRIG IN
14 TRIG IN RTN
15 SYNC OUT
16 SYNC OUT RTN
17 POWER CONT IN
18 POWER CONT RTN
shell FRAME GND
(00375)
Direction Function ・Input/Output Level
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
I/O 10/100/1000BASE-T Interface
IN CMOS, contact
IN CMOS, contact
IN High impedance
IN High impedance
IN CMOS, contact
IN CMOS, contact
OUT CMOS
OUT CMOS
IN CMOS, contact
IN CMOS, contact
－ Frame ground
4-19
Input/Output Connectors
Notes
Insulator
Ground insulator
Isolation
transformer
Isolation
transformer
Insulator
Ground insulator
Insulator
Ground insulator
Insulator
Ground insulator
