System Control

System Control

CAMERA MODE LED (1/2)
LED Status
REC mode.
Displays trigger detection status while the camera image is being record-
ed by memory. Indicates the recording status to the recording memory by
Orange
changing the brightness of orange due to light and dark.
After the trigger input, it changes from light to dark.
The less frames remaining, the darker the orange brightness.
ARM mode.
From the time ARM is started until the time the picture is recorded for the
number of frames before the trigger.
Yellow A change in brightness due to light and dark in yellow indicates the record-
ing status to the recording memory. Dark to Light: Indicates the lapse rate
of recording for the number of frames before triggering. It turns white when
recording is complete for the number of frames before triggering.
ARM mode.
Recorded memory is discarded, and the camera image is being recorded to
memory. Displays the recording status to the recording memory with the
change of white brightness due to light and dark.
The ratio of the light/dark changes varies depending on the trigger timing
White
setting.
Dark to Light: Indicates the lapse rate of recording for the number of frames
before triggering.
Light to Dark: Indicates the lapse rate of recording for the number of frames
after triggering.
Recording memory is full and cannot be recorded.
Blue The camera is not recording video, but a live video is displayed (VIEW
mode).
Not lit Power OFF or sleep state.
Set to EST mode, and EST pulse is input.
Flashing However, only ARM mode and REC mode. Flashing by alternately turning on
and off.
Operation
100
