Input/Output Connectors
SYNC OUT
PWRCTL
Signal level：
5VCMOS output, insulator
Function：
Falling (Ｈ→Ｌ) ：Start exposure
Rising (Ｌ→Ｈ) ：End exposure
Polarity inverting function
Signal level：
CMOS level, 5V pull-up, insulator
L level：-0.5VDC (minimum applied voltage)
1.2VDC
H level ： 3.6VDC ～ 5.5VDC (maximum applied
voltage)
Function：
H：Power ON
L：Power OFF
No polarity inverting function
4-18
～
(00375)
