Shape, Environment, Precision, Application Standards, Supplies

Shape,
Application Standards, Supplies
■ Shape
Exterior dimensions (W×H×D)
Main unit weight
Mounting screws
■ Environment
Operating temperature and
humidity
Storage temperature and
humidity
Vibration
Impact
■ Precision
Precision of recording time
Method of inspecting the
precision of recording time
■Application Standards
Safety standard
Electromagnetic compatibility
■ Supplies
Memory backup battery
Environment,
About W62×H62×D65mm (Excluding connector, protruding parts and
mounting parts)
About 470g (Camera unit only. Excluding mounting cap and such)
4 each M4 depth of 5mm on the top, bottom, left and right
4 each M4 depth of 7mm on the front and back
0～40℃, 30～80%RH (no condensation)
-10～60℃, 20～80%RH (no condensation)
Conforms to MIL-STD-810C METHOD 514.2 CATEGORY b2
(RANDOM VIBRATION ENVELOPE) FIGURE514.2-2A
Half sine, 10msec, 150G
±0.01% or less
The value of the reciprocal of the frame rate (frequency) for a given
time (1 sec or more) is applied as the precision time.
Measures the frequency of the EPO signals output from the REMOTE
connector with the frequency counter for the recording rate within a
given amount of time (1 sec or more).
EN60950
EN55022, EN55024, FCC Part 15 Class A
Depletion rate：
Replacement method：
4-20
1 year (Target annual replacement due to the great
discrepancies from ambient temperature and use
environment)
Replacement by our company
Precision,
