Status LED

Status LED

Confirmation of the MEMRECAMC Q1m/Q1v status can be made with the status LED.
Status LED
The four status LED on the right side of the unit display the camera status.
LED Status LED
Orange
(Flashing)
Blue
White (Flashing)
MODE
Purple
(magenta)
(Flashing)
Not lit
Green
STATUS Red
Not lit
Orange
ETHER Flashing green
Not lit
Green
Flashing green
Orange
MEM BACKUP Flashing orange
Red
Flashing red
Not lit
REC mode (Flashing：set to EST mode, EST pulse input)
STOP／READY mode
VIEW mode (Flashing：set to EST mode, EST pulse input)
ARM mode (Flashing：set to EST mode, EST pulse input)
Power OFF or operating
Power ON, normal operation
Power ON, fail state
Power OFF
Network communicating at 1000BASE-T
Network communicating at 100BASE-TX
No network connection
Memory backup, DC input, battery (maximum charge)
Memory backup, battery only (maximum charge)
Memory backup, DC input, battery (charging)
Memory backup, battery only (charging)
Memory backup, DC input, battery (low battery charge)
Memory backup, battery only (low battery charge)
Memory backup, (no recorded data)
2-10
Operation
