Input/Output Connectors
■IF Connector
Application
Model
Plug
ETHER
SYNC IN
DC IN
TRIG
(00375)
Camera power input, Ethernet connection, EST input, trigger input,
EPO output, power control
LEMO ECA.2B.318
LEMO FGA 2B.318
1000BASE-T (IEEE802.3ab), 100BASE-TX (IEEE802.3u), insulator
Signal Level：
CMOS level, 5V pull-up, insulator
L level：-0.5VDC (minimum applied voltage)
1.2VDC
H level ： 3.6VDC ～ 5.5VDC (maximum applied
voltage)
Function：
Set to EST mode and start exposure H→L during
the ARM or REC mode and photograph film one
Synchronous precision of 1.5μs or less
Polarity inverting function
During EVENT input, the signal level is recorded
together with the image
Power voltage：
DC 20～32V
Input power：
DC power (AC adapter)
Power consumption：About 22W (ARM MODE, DC24V)
Power protection： Reverse polarity
by the user)
Overvoltage
Signal level：
CMOS level, 5V pull-up, insulator
L level：-0.5VDC (minimum applied voltage)
1.2VDC
H level ： 3.6VDC ～ 5.5VDC (maximum applied
voltage)
Function：
Trigger functions with H→L, polarity inverting
function
4-17
Input/Output Connectors
Internal fuse (can be replaced
35VDC, 1 minute
～
～
