Chapter 9: Troubleshooting
3. Grasp the replacement tip with the pliers and insert it
into the sleeve.
4. Push the probe tip into a soft surface, such as card-
board, until it hits the bottom of the sleeve.
NOTE: To obtain replacement tips, contact Midtronics Cus-
tomer Service. (See Patents, Limited Warranty, Ser-
vice.)

FILE NOT FOUND

If the last file created, opened, or used does not match any
files on the memory card, the analyzer will beep and display
FILE NOT FOUND. The analyzer's internal EEPROM memory
stores the last test used. When the analyzer powers on, it
looks for the last file used on the memory card. To prevent
the message from reappearing when you turn on the
analyzer, insert the card containing the file, open an existing
file, or create a new file on the card.
Data is corrupt on the memory card
If you are unable to select a string name, or the display
shows garbled characters, the data on the card might be
corrupt. Try to salvage the files by copying them to your PC
using the card reader included in the kit (USB port required).
Reformat the memory card using the FORMAT option in the
BATTERY SETUP menu. Do not copy the files
memory card.
If the label has been removed, make sure the tab on the
card is in the locked position. To avoid corrupting the data,
do not unlock the card to copy files from the PC. When you
purchase a new SD card, place the tab in the locked position
before using.
Test results do not print or print incorrectly
STATUS LED
When a printer fault occurs, the
can identify the fault by the number of sequential flashes:
Solutions
If the IR transmitter and receiver are not aligned,
*** *** ***
BACK
STATUS
LED flashes. You
Sequence
* * *
Paper ou
** ** ** Thermal head too hot
Batteries low
all the data may not print. The infrared ports on the top of
the analyzer and on the printer (below the MODE button)
should be pointed directly at each other. The maximum
distance for reliable transmission between the ports is 18
inches (45 cm).
To realign, press the
alignment between the analyzer and printer; then try to
print the test results again.
If the message PRINTING appears on the screen,
but no data are printing, press the
print. Turn off the printer and charge the printer battery for
at least 15 minutes before attempting to print again. Align
the analyzer and printer IR transmitters and print again.
Make sure the printer is on. The printer shuts off
after two minutes of inactivity to conserve the battery. To
turn the printer on, briefly press the
STATUS
green
using the Midtronics printer provided with the Celltron
ULTRA. Other printers may not be compatible.
Direct sunlight interferes with infrared data
transmission/receiving. If the printer is not receiving data,
remove the printer and the Celltron ULTRA from direct
sunlight. If the printed characters are not clear or are
partially missing, recharge the battery and reprint.
to the
Verify that the correct printer is selected in the
analyzer . Press the ARROW keys to highlight the UTILITIES
SETUP icon in the Main Menu, and press
Verify that a compatible communications protocol
is selected in the printer setup. IrDA Mode is compatible
with the Midtronics printer ("IRDA Physical Layer" on the
printer's self-test printout). Refer to the printer manual for
information.
If you are unable to print after ensuring the analyzer
is functioning, the printer is on, the batteries are good, and
the IR transmitter and receiver are aligned, see the printer
manual for further instructions or call Midtronics. (See
Patents, Limited Warranty, Service.)
Condition
t
Fit new paper
Allow head to cool
Recharge printer batteries
for 16 hours
50
• •
BACK
key to cancel the print. Verify
BACK
MODE
light should turn on. Make sure you are
ENTER
Solution
Celltron ULTRA
key to cancel the
button. The
.
