Chapter 2: Description

Selection screens

When you turn on the analyzer it will default to the last
menu screen displayed. To move back to the Main Menu,
BACK
press the key as each submenu appears.
The Main Menu has six menus: BATTERY SETUP, TEST,
REPORTS, UTILITIES SETUP, DMM (Digital Multimeter), and
BATTERY MANAGER. The menus have several submenus
or options to help you set up the analyzer for testing,
automate portions of the test process, and manage test
data. The settings contain factory defaults that you can
overwrite using the keypad. For more information, refer to
the sections in the manual on selecting test parameters and
utilities. The keys you use to enter data depend on the type
of selections displayed. There are four types:
Menu icons
A menu icon is a graphical representation of a function you
can select and use, such as the BATTERY SETUP icon in the
Main Menu.
To select an icon, use the
highlight it, and press the
previous menu, press the
ARROW
( or ) keys to
ENTER
key. To return to the
BACK
key.

Scrolling lists

Scrolling lists contain items that extend above and below
the screen or the selection box that contains them. To
indicate that there are more items, the symbols
the right of the first item on the list. To select from a list, use
ARROW
the keys to scroll to the item and press
Check boxes
Lists that fit the screen have check boxes before each item.
ARROW keys
Use the
to your selection, or use the numeric keys to enter the item
ENTER
number. Press
Alphanumeric selections
Some selections require you to use the alphanumeric
keypad. These "user-defined" selections are indicated by
a blinking horizontal line (cursor) to the right of the last
character. Display the character, symbol, or number you
want by rapidly pressing its key as many times as needed. If
you pause, the cursor moves to the right. To backspace one
character, press the
characters, press the key twice. Press
8
• •
Celltron ULTRA
to place the check in the box next
to select.
BACK
key. To enter a space between
ENTER
when finished.
appear to
ENTER
.
