Celltron ULTRA
If you are testing a string for the first time, use the NEW test
menu in BATTERY SETUP to create a string name and choose
its test parameters. If you make no selections, the analyzer
uses the default settings when you test the string. (See
Menu structure in Chapter 2.)
To begin: Make sure the memory card is inserted correctly.
The card's label should face the keypad. Press and hold the
POWER
button.
• The first time you turn on or connect the Celltron
ULTRA, it will display a reminder to set preferences
for the temperature units (Celsius or Fahrenheit)
and the jar and string WARN/FAIL thresholds.
Although you can press the
the message, it will continue to appear until you
change or accept the default settings.
• To protect its circuitry, the analyzer will not turn
on if the clamps/probes are connected in reverse
polarity (red to negative, black to positive).
• If the last file created, opened, or used does not
match any files on the memory card, the analyzer
will beep and display FILE NOT FOUND. The
analyzer's internal EEPROM memory stores the
last test used. When the analyzer powers on, it
looks for the last file used on the memory card. To
prevent the message from reappearing, insert the
card containing the file, open an existing file, or
create a new file on the card.
Creating a string name (FACTORY TEST)
A string name stores your test parameters, eliminating the
need to reenter data each time you test. The default name
is FACTORY TEST (or the last name created), which you can
overwrite with any 20-character combination of letters,
numbers, or symbols using the alphanumeric keypad.
ARROW keys
1. Press the
ENTER
UP icon, and press
ARROW keys
2. Press the
ENTER
press .
3. When the prompt RENAME NEW STRING appears, press

Chapter 5: Selecting test parameters

BACK
key to bypass
to highlight the BATTERY SET-
.
to highlight the NEW icon, and
Chapter 5: Selecting test parameters
ENTER
to create a new string name.
4. The default string name or the last string tested will ap-
ENTER
pears. Press
5. The cursor will blink to the right of the last character. To
backspace and overwrite characters, press the
key as many times as needed.
6. Enter the character, symbol, or number you want by
rapidly pressing its key as many times as needed. If you
pause, the cursor moves to the right. To enter a space
between characters, press the
ENTER
7. Press when finished.
8. The string name you created appears at the top of the
parameters list. The name is highlighted, enabling you
ENTER
press to change it again before selecting your
test parameters. To continue selecting parameters press
ARROW
the keys. Creating a TECH ID
ENTER
Press to create a technician ID of up to 20
alphanumeric characters. The ID will be linked to the new
string ID. The default name is TECH ID (or the last ID created),
which you can overwrite with any combination of letters,
numbers, or symbols using the alphanumeric keypad.
ARROW keys
1. Press the
default) or the last ID created.
2. The editing screen will appear. The cursor will blink to
the right of the last character. To backspace and over-
write characters, press the
needed.
3. Enter the character, symbol, or number you want by
rapidly pressing its key as many times as needed. If you
pause, the cursor moves to the right. To enter a space
between characters, press the
ENTER
4. Press when finished.
Selecting the number of JARS PER STRING
The default is 24. The number of jars you can test depends
on whether you are testing JARS ONLY, JARS & 1 STRAP, or
JARS & 2 STRAPS and number of POSTS PER JAR.
25
• •
for the editing screen.
key twice.
to highlight TECH ID 1 (factory
BACK
key as many times as
key twice.
BACK
