Celltron ULTRA
Turn on the printer by pressing the MODE button.
1.
ARROW keys
2. Press the
ENTER
and press .
ARROW keys
3. Press the
ENTER
and press .
ARROW keys
4. Press the
ENTER
press .
ARROW keys
5. Press the
ENTER
and press .
6. Align the analyzer's IR transmitter (to the right of the
cable connector) with the IR receiver on the printer (be-
low the MODE button).
PRINT
7. Press the key. Keep the IR transmitter and re-
ceiver aligned for as long as it takes to print.
8. Repeat steps 5, 6, and 7 for each screen you want to
print.
BACK
9. Press the key to end.
Transferring test results to a PC with the IR
receiver (TRANSFER)
You can transfer one file at a time or all files simultaneously
to a PC with the software and IR receiver included in
the kit.
After installing the software according to the installation
instructions:
ARROW keys
1. Press the
PORTS icon in the Main Menu, and press
ENTER
.
ARROW keys
2. Press the
icon in the REPORTS MENU, and press
To transfer data for every string tested:
3. Align the analyzer's IR transmitter (to the right of the
cable connector) with the IR receiver.
4. Place a check in the box next to TRANSFER ALL DATA,
ENTER
and press . The Main Menu appears when the
transfer is complete.
To transfer data for a particular string:
3. Align the analyzer's IR transmitter (to the right of the
cable connector) with the IR receiver.
4. Place a check in the box next to SELECT FILE. Scroll to
the string name containing the test data you want to
to highlight the REPORTS icon,
to highlight the JAR DATA icon,
to select the string name, and
to select a jar or strap screen,
to highlight the RE-
to highlight the TRANSFER
ENTER
.
Chapter 7: Test results and reports
transfer, and press
seconds to transfer after which the Main Menu ap-
pears.
Transferring files to a PC from the memory
card
The Celltron ULTRA uses an SD memory card to store test
data, which can be uploaded to a PC. An SD card reader,
which connects to a USB port, is included in the kit. The
files have the extension .csv and open in Microsoft Excel.
You can purchase SD memory cards at any office supply or
computer store. Starting with the Revision H software, the
Celltron ULTRA accepts 32 MB to 1 G cards. Larger storage
sizes are not compatible.
IMPORTANT:
The memory card stores data as "read
only. " To avoid corrupting the data on the card, do
not remove the label and unlock the card to copy
files from the PC. When you purchase a new SD
card, make sure its tab is in the locked position be-
fore using. The Celltron ULTRA can read and write
files when the card is in the locked position. Always
keep the card's tab in the locked position to prevent
files from being corrupted by your PC's operating
system. Format the card using the FORMAT option
in BATTERY SETUP before using.
1. Connect the card reader to the USB port on the PC.
2. Insert the memory card into the card reader.
3. Save the files into a directory on your hard drive.
Additional options in the
In addition to the test data options, the REPORTS menu has
two sources of information that are helpful in tracking the
analyzer's usage and software maintenance:
Counting the number of tests performed

(TEST COUNTER)

The Celltron ULTRA automatically keeps track of the number
of tests performed. Select the TEST COUNTER icon and press
ENTER
to see the total number of tests performed since
the analyzer was first used.
Finding the analyzer software VERSION
Select the VERSION icon and press
serial numbers of the analyzer, cable, flash memory, and
EEPROM firmware versions. The information will be helpful
when you call Midtronics for software updates, service, and
parts.
45
• •
ENTER
. The data will take several
REPORTS
menu
ENTER
to display the
