Guidelines
• Do not place clamps or probes on stainless
steel hardware, such as bolt heads, washers, or
threaded posts. Stainless steel hardware can yield
low conductance values. If you have to test on
stainless steel, record it in your testing records.
• The jars might have grease on the terminals and
connections to prevent corrosion. You do not
have to wipe off the grease before attaching the
clamps or connecting the probes.
• Test each jar in the same location or position.
Changing the location of the test point might vary
test results.
Attaching the cable to jar posts
1. Attach the black clamp or probe tip to the black (–) ter-
minal. Refer to Figure 5.
2. Attach the red clamp or probe tip to the red (+) termi-
nal.
Selecting the last used test setup with the
TEST option
If you select the TEST option in the Main Menu and connect
to a battery, the analyzer tests using the parameters from
your last test setup or, if there is no setup in memory, the
default parameters.
Using the OPEN option
The OPEN option enables you to view the parameters of
a saved test setup. You can also use OPEN to change any
parameters EXCEPT:
JARS ONLY / JARS & 1 STRAP / JARS
& 2 STRAPS
POSTS PER JAR
JARS PER STRING
VOLTS PER JAR
VOLT & CONDUCTANCE / VOLT-
AGE ONLY / VOLTS THEN
CONDUCT(ANCE)
If you change these parameters you will erase the string's
test data. If you need to change them, use the NEW (TEST)
function and save the setup.
To use the OPEN option:
Figure 5: Attaching the cable to jar posts
ARROW keys
1. Press the
UP icon in the Main Menu, and press
ARROW keys
2. Press the
the BATTERY SETUP menu, and press
ARROW keys
3. Press the
ENTER
.
4. The analyzer will alert you that testing for that string
was completed:
TO SET UP AND TEST A
NEW STRING, PRESS 'C'
THEN SELECT 'NEW'
5.
Scroll through the list and verify or change parame-
ters.
6. Scroll to SAVE AND CONTINUE to exit or SAVE AND TEST
to test a string.
NOTE:
If you are not connected to the jar, the an-
alyzer prompts you to connect. Connect the clamps
or probes, and press
IMPORTANT:
If you are measuring VOLTS THEN CON-
DUCTANCE, disconnect from the last jar in the string
after the voltage test. Reconnect to the first jar and
ENTER
press
displays TESTING JAR 1 when you reconnect.)
The analyzer beeps twice when the test is done. The
analyzer beeps longer if:
35
Chapter 6: Testing
to highlight the BATTERY SET-
ENTER
to highlight the OPEN icon in
ENTER
to select a test setup, and press
TESTING OF STRING
IS COMPLETE
ENTER
to start the test.
to test for conductance. (The analyzer
.
.
