Chapter 2: Description
LOW VOLTAGE (scrolling/numeric)
The range (1.000 to 22.000) depends on the VOLTS PER JAR.
JARS ONLY
ENTER
Press
MODE (check boxes)
JARS ONLY
Test only the jars on the string.
JARS & 1 STRAP
Test jars and their connections on the string.
JARS & 2 STRAPS
Test jars and their connections on the string.
POSTS PER JAR
ENTER
Press
POSTS PER JAR (scrolling/numeric keys) Select 2, 4, 6, or 8.
BATTERY MANAGER (scrolling)
ENTER
Press
SELECT MANUFACTURER
ENTER
Press
SELECT MFGR (scrolling/alphanumeric)
Select from an alphabetical list of approximately 16 manufacturers, or select USER VENDOR (three
available) to create a name for an unlisted manufacturer.
SELECT MODEL (scrolling/alphanumeric)
Select from an alphabetical list of over 200 models, or select USER DEFINED (approx. 64 available) to
create a name for an unlisted model.
REFERENCE DEVELOPER
ENTER
Press
REF DEVELOPER (scrolling/numeric)
Select a percentage of jars on the string on which to base a reference (from 0 to 100%).
REFERENCE (scrolling/alphanumeric)
The default is dashes (
ENTER
Press
selected in BATTERY MANAGER. If you use REFERENCE DEVELOPER, the setting displays asterisks (
cannot be changed.
VOLT & CONDUCTANCE (default)
ENTER
Press to measure volts only; volts and conductance simultaneously; or voltage first, then conductance.
MODE (check boxes)
VOLTAGE ONLY
VOLT & CONDUCTANCE
VOLTS THEN CONDUCT(ANCE)
TEMPERATURE
ENTER
Press to select the units of measure and the temperature of the string. Conductance measurements
to select a test mode.
to select the number of posts per jar.
to select a jar manufacturers and model, and computer a reference value.
to display jar manufacturers and models.
to have the analyzer compute a reference value.
).
– – – – – –
to change the value. This setting uses the manufacturer's reference value for the model of jar
