Chapter 4: Utilities

The UTILITIES SETUP menu has eight options, three of which
support the test process. If you make no selections, the
analyzer uses the default settings. For the critical WARNING
and TEMP settings, the analyzer will remind you with a
PREFERENCES NOT SET message until you change or accept
the default settings.
The utilities are:
• WARNING (voltage threshold for failing jars and
strings)
• TEMP (Celsius or Fahrenheit)
• MODE (auto or manual test startup)
• CLOCK (date and time)
• DISPLAY (contrast and backlight duration)
• LANGUAGE (selecting the language)
• UPDATE (update the Celltron ULTRA software)
Selecting a warn/fail threshold (WARNING)
The WARNING utility enables you to set the percentages
of the reference value below which a jar and string must
fall to generate a WARN or a FAIL notice on the printed test
results. A question mark (?) appears next to jars and strings
as a warning. An exclamation mark (!) appears if the jar or
string is failing.
Table 4: Defaults for a jar and string in service
STRING WARN
<70%
STRING FAIL
<60%
ARROW keys
1. Press the
in the UTILITIES SETUP menu, and press
ARROW keys
2. Press the
press .
ARROW keys
3. Press the
WARN, STRING FAIL, JAR WARN, or JAR FAIL and press
ENTER
ARROW keys
. Press the
ENTER
and press
to select. Repeat the process for each
screen you want to print.
Chapter 4: Utilities
JAR WARN
<70%
JAR FAIL
<60%
to highlight the WARNING icon
ENTER
.
to select a STRING NAME, and
to scroll to a selection: STRING
to set percentages,
Selecting Celsius or Fahrenheit (TEMP)
Select Celsius or Fahrenheit as a unit of measure before
setting your test parameters in BATTERY SETUP. The last
saved TEMP selection becomes the default unit of measure.
ARROW keys
1. Press the
UP icon, and press
ARROW keys
2. Press the
ENTER
press
.
ARROW keys
3. Press the
ic keys) to check the box next to DEGREES F or
DEGREES C, and press
Selecting a manual or automatic test-start
mode ( MODE)
The MODE utility has two test-start modes. AUTO START
starts a test automatically when you connect to the next jar
from the jar results screen. The setting allows you to keep
your hands free to use probes.
MANUAL START, which is the default, prompts you to press
ENTER
to begin a test after you connect to the jar.
ARROW keys
1. Press the
the UTILITIES SETUP menu, and press
ARROW keys
2. Press the
check the box next to MANUAL START or AUTO START.
ENTER
3. Press
to select.
BACK
4. Press the
menu.
Setting the date and time (CLOCK)
The clock utility includes settings for the analyzer's 24-hour
internal clock and for the date and time, which are printed
on test reports. Although the date and time are set at the
factory, you may need to make changes based on your time
zone.
1. Press and hold the
turns on.
ARROW keys
2. Press the
22
Celltron ULTRA
to highlight the UTILITIES SET-
ENTER
.
to highlight the TEMP icon, and
(or use the numer-
ENTER
to select.
to highlight the MODE icon in
ENTER
(or use the numeric keys) to
key to return to the UTILITIES SETUP
POWER
button until the analyzer
to highlight the UTILITIES SET-
.
