Infrared LED: 21 IR LEDs, night visibility up to 20 meters
LENS: CMOS sensor with zoom lens
Back View
WIFI Antenna: Wireless Antenna
Interface View
1) I/O alarm terminal
This network camera provides a I/O alarm terminal block which is used to connect to
external input / output device. The pin(there are four number in the terminal block from
no. 1 to no. 4) definitions are descripted below:
24-9-2015
block
Figure 7.2
Figure 7.3
7
Antenna
ebode IPV68P2P
