Ebode IPV68P2P User Manual page 15

Step 1) Login to the router, and go to your router's port forwarding or port triggering
menu. Sometimes this is also under the name of Virtual Server or NAT.
Using the Linksys brand router as an example, we would log into the router, and go to
the Applications & Gaming menu. We would then click on the "Single Port Forwarding"
sub-menu.
Step 2) Create a new column using the LAN IP address & HTTP Port of the camera within
the router as shown below, then push OK or Submit to save your settings:
Assign a name for the
port forward setting here.
First method:
Use the embedded DDNS to access the camera via the Internet
Each camera has an embedded unique DDNS domain name, the format of this domain
name is xxxxxx.myipcamera.org. On the bottom of the camera, you can see the domain
name sticker with this information on it.
For example, we can use test09.myipcamera.org. In the camera, click Settings at the
top, click "Network" on the left, then click "DDNS" to get to the DDNS settings page.
Here you can see the unique domain name of your camera.
24-9-2015
Fill the HTTP Port of
the camera in the
columns of External
Port and Internal Port.
Example: 2000
Figure 8.12
Figure 8.13
15
Fill in this
section with the
LAN IP of the
camera; we
would enter
"100" for our
example.
ebode IPV68P2P
