Ebode IPV68P2P User Manual page 43

Firstly, goes to option of DDNS Settings on the administrator panel.
Secondly, select No-Ip as a server..
Thirdly, fill test as DDNS user, fill password test2012 as DDNS password, fill ycxgwp.no-
ip.info as DDNS domain and server URL, Then click save to make effect. The camera will
restart and to take the DDNS settings effective.
Fourthly, after the restart, login the camera, and go to option of Device Status on the
administrator panel, and check if the DDNS status is successful.
If failed, please double check if you have input the correct hostname, user name, and
password, and try to redo the settings.
NOTE: If you have set Third Party DDNS successfully ,the Domain Name will be invalid.
The Third Party DDNS and the Domain Name cannot work at the same time, the last
time you configured will take effect.
② Do port forwarding within the router
Example: The camera's LAN IP address is http://192.168.8.100:2000 , Media port no. is
9200.
Firstly, login the router, goes to the menu of Port Forwarding or Port Trigger (or named
Virtue Server on some brands of router). Take Linksys brand router as an example,
Login the router, and goes to Applications & Gaming->Single Port Forwarding.
Secondly, Create a new column by LAN IP address & HTTP Port No. of the camera within
the router showed as below.
③ Use domain name to access the camera via internet
After the port forwarding is finished, you can use the domain name+ http no. to access
the camera via internet. Take hostname ycxgwp.no-ip.info and http no. 2000 for
example, the accessing link of the camera via internet would be http:// ycxgwp.no-
ip.info:2000
24-9-2015
Figure 10.31
43 ebode IPV68P2P
