Step 2) Enter the username and password of the Administrator (default username is
admin with a blank password), and click "OK" to apply changes.
Step 3) Wait around 10 seconds, you'll see that the camera's LAN IP address has
changed. In our example it was changed to 2000, so we see http://192.168.8.102:2000
in IP Camera Tool. Also, the LAN IP address is now fixed at a static IP address of
http://192.168.8.102:2000. This IP address will not change even if the camera is
powered off and back on, the camera will remain on this LAN IP address. This is very
important that a static LAN IP address is set, or you may have problems later with
remote access and seeing the camera remotely if the camera loses power and reconnects
on a different LAN IP address. Make sure you set a static LAN IP address!
What is Port forwarding?
If you have never done port forwarding before, you can open and view the following link
to understand the basic concept. Port forwarding allows for outside connections to access
a specific device on your network from anywhere in the world. Every router automatically
blocks any incoming connections for safety purposes. Using port forwarding, you are
telling your router to allow a connection through a certain port (you can think of it as a
gateway) into your router. You set this port to a specific device, in our case an IP
Camera, so it can be accessed from anywhere in the world.
Learn more about port forwarding: http://portforward.com/help/portforwarding.html
How do we configure Port Forwarding?
For this section, we will be using an example:
Let's say the camera's LAN IP address is http://192.168.8.100:2000
24-9-2015
Figure 8.10
Figure 8.11
14
Modify the Http
Port.
Enter the
Username and
password, click
OK.
