The firmware inside the camera supports up to maximum of 9 cameras being monitoring
at the same time. You can add other cameras in multi-device setting.
Figure 9.9
Section 3 - Mode/ Stream / Mirror/ Flip / Zoom in / Zoom out buttons
Mode
1) 50HZ ---------Indoor surveillance (Region: Europe, China)
2) 60HZ ---------Indoor surveillance (Region: USA, Canada)
3) Outdoor Mode ------ Outdoor surveillance
Stream
The default stream supports multiple modes, For example: HD Mode/720P/30fps/2M
meanings: Stream type / Resolution / Maximum frame rate/ Bit rate. (Different models
support different specific mode. )
1) Stream type. :It is used to identify the stream type.
2) 720P/ VGA
There are two resolutions, the bigger one is 720P, and the smaller one (VGA) is 640x480
pixels. The bigger the resolution, the better of the image quality is. If you are accessing
the camera via internet and want to get more fluent video streaming, please select
resolution VGA.
3) Maximum frame rate
When the video format is 50Hz, the maximum frame rate is 25 fps. When the video
format is 60Hz, the maximum frame rate is 30 fps. You should lower frame rate when
the bandwidth is limited. Normally, when the frame rate above 15, you can achieve
fluently video. The maximum frame rate for each model is different, please see the
"Default Parameters".
4) Bit rate
Generally speaking, the larger the bit rate is, the clearer video will become. But the bit
rate configuration should combine well with the network bandwidth. When the bandwidth
is very narrow, and bit rate is large, that will lead to video cannot play well.
You can reset the stream type on Settings-> Video-> Video Settings panel.
