Ebode IPV68P2P User Manual page 45

Another way to change the HTTP port NO.
Step 1: Open the IP Camera Tool, select the camera you would like to change the port
of, right click on the IP address, and click on "Network Configuration", this brings up the
network configuration box as shown in Figure 10.35 and 10.36.
Step 2: Enter the username and password of the Administrator (default username is
admin with a blank password), and click "OK" to apply changes.
Step 3: Wait around 10 seconds, you'll see that the camera's LAN IP address has
changed. In our example it was changed to 2000, so we see http://192.168.8.102:2000
in IP Camera Tool. Also, the LAN IP address is now fixed at a static IP address of
http://192.168.8.102:2000. This IP address will not change even if the camera is
powered off and back on, the camera will remain on this LAN IP address. This is very
important that a static LAN IP address is set, or you may have problems later with
remote access and seeing the camera remotely if the camera loses power and
reconnects on a different LAN IP address. Make sure you set a static LAN IP address!
24-9-2015
Figure 10.35
Figure 10.36
45
Select which
camera you'd like
to change the port
for, and right click.
Modify the Http
Port.
Enter the
Username and
password, click
OK.
ebode IPV68P2P
