Figure 10.52
There are four alarm indicators:
A Camera Sound and PC Sound
If the camera has connected with a speaker or other audio output device, if you select
Camera Sound or PC Sound, when the motion has been detected, the people around the
camera will hear beep alarm sound.
B Send E-mail
If you want to receive alarm emails when motion is detected, you must select Send E-
mail and set Mail Settings first. The alarm email cannot contain the alarm picture if you
have not selected Take Snapshot.
C Take Snapshot
If you select this check-box, when the motion has been detected, the camera will snap
the live view window as a still picture and load it to the FTP. Make sure you have set FTP
and set FTP as the storage path in Video->Snapshot settings panel.
If you select Send Email, at the same time the picture will be send to you as an
attachment.
Time interval: The interval time between two pictures.
D IO Output
If IO alarm is triggered and IO alarm output device will always alarm (sound alarm is
issued a warning sound, alarm lights in flash etc.). Click "Clear IO alarm output" , the
alarm output device will stop alarming. If IO alarm is triggered again after alarm
interval, IO alarm output device will be restart.
E IO Output
If IO alarm is triggered and IO alarm output device will always alarm (sound alarm is
issued a warning sound, alarm lights in flash etc.). Click "Clear IO alarm output" , the
alarm output device will stop alarming. If IO alarm is triggered again after alarm
interval, IO alarm output device will be restart.
5.) Set detect area
Click set detect area and it pop up a window, then you can draw the detection area. Click
OK button after settings. When something moving in the detection area, the camera will
alarm.
