Ebode IPV68P2P User Manual page 63

Thirdly: Click OK button and the cruise track will take effect.
You can add other cruise track as the same method.
For example: I have added three preset points to the "track
1", that means: When I select the "track 1" on the
surveillance window, the camera moves as the following
track: upright then Right Most last downleft.
Add preset on the left of the surveillance window.
After add the cruise track, back to the surveillance window, click Cruise, here you can
see all cruise tracks you have added.
There are other buttons between the Preset points and Cruise track, you can use these
buttons to adjust the order of preset points or add/delete one preset points in one cruise
track.
24-9-2015
Add the preset.
Figure 10.73
Figure 10.74
63
Figure 10.72
The cruise tracks have
added to the "track 1" .
ebode IPV68P2P
