Safety Level Interface

The daughter board must be installed only in the products authorized by
OneAccess and only by qualified personnel as recommended in the
installation manual.
1.4.1 LAN Interface 10/100 Mbps (ETHERNET and/or SWITCH)
Interface marking on the router back panel: ETHERNET and SWITCH
The Ethernet 10/100 Mbps auto-sense has a 'SELV' (Safety Extra Low Voltage)
interface.
They must be used only for indoor applications, connected to a 10/100 Mbps
interface, which has also the 'SELV' characteristics.
1.4.2 ADSL, ADSL 2/2+, RE-ADSL (ADSL)
Interface marking on the router back panel: ADSL
The router has an ADSL interface TNV-3 type (Telephone Network Voltage),
designed for connection to a telephone line.
1.4.3 PSTN Modem Interface (PSTN)
Interface marking on the router back panel: PSTN
The analog MODEM interface V.32 (bis)/V.34/V.90/V.92 is 'TNV-3'. It must be
connected to a standard telephone line.
1.4.4 RS 232 Interface (V.28)
Interface marking on the router back panel: V.28
The interface is SELV. It must be used only for indoor applications and connected to
RS 232 interfaces, which are also designed as 'SELV'.
1.4.5 FXS Interface (FXS)
Interface marking on the router back panel: FXS
The FXS modules offer up to 8 FXS accesses (RJ45 connectors). These Interfaces
are 'TNV 2' (Telephone Network Voltage).
1.4.6 FXO Interface (FXO)
Interface marking on the router back panel: FXO
