B-2. V.28 / RS 232 DCE Cable
Catalog reference: 9594 508 07146
P1
43
- P1 -
RJ45
1
2
3
4
5
6
7
8
Screening
ONE100 - Installation Manual
P2
SIGNAL
115 (RXC)
105 (RTS)
104 (RD)
109 (CD)
103 (SD)
108 (DTR)
102
106 (CTS)
P2 -
SUB-D 25 Pts
female
17
4
3
8
2
20
7
5
Shield
