Configuration without impedance adaptation and power feeding of the terminal:
Configuration with impedance adaptation and without power feeding of the terminal:
Configuration without impedance adaptation and with power feeding of the terminal:
Configuration with impedance adaptation and with power supply of the terminal:
34
Configuration
Configuration
Configuration
Configuration
ONE100 - Installation Manual
100 Ohms impedance adaptation
disconnected.
Power feeding for ISDN terminal
disconnected.
100 Ohms impedance adaptation
connected. The first jumper of the pair is
associated with the transmission, the
second one with the reception.
Power feeding for ISDN terminal
disconnected.
100 Ohms impedance adaptation
disconnected.
Power feeding for ISDN terminal
connected.
100 Ohms impedance adaptation
connected. The first jumper of the pair is
associated with the transmission, the
second one with the reception.
Power feeding for ISDN terminal
connected.
