1

Safety Instructions

The following symbol instructs the user to read the manual carefully before any
connection:
1.1

Connection to Power Supply

To connect the power supply, always follow these steps:
•
Connect the DC input jack from the power supply to the DC 12V power input
on the rear panel of the router,
•
Connect the power supply to an AC electrical outlet (100-240 VAC). Plugging
in the power supply turns on the router.
Unplug the AC input before assembling/disassembling any part on the
device. The AC input is the part you must disconnect first. For safety rea-
sons, you shall be able to easily access this part.
1.2

Overcurrent Protection

The product requires that the building's electrical installation is designed for
protection against short-circuit (over current) protection.
A fuse or circuit breaker no larger than 240 VAC, 10A must be used on the phase
conductors.
1.3

Safety Level Interface

All safety levels of the interfaces are described in each paragraph presenting the
interfaces (paragraphs 3.1 to 3.4).
The interface modules and optional boards can be installed only in the
products authorized by OneAccess and only by qualified staff as
recommended in the installation manual.
