Summary of Contents for OneAccess ONE100
- Page 1 ONE100 Installation Manual September 2008 http://www.oneaccess-net.com...
- Page 2 OneAccess. OneAccess and the distributors can in no case be held responsible for direct or indirect damage of any kind incurred as a result of any error in the software or guide.
-
Page 3: How To Read This Manual
Chapter 7 – Power-up This chapter describes the device power-up and how to monitor the self-test progress. Appendix – Connection description These chapters provide the pin-out of cables that are compatible with the router. ONE100 - Installation Manual... -
Page 4: Table Of Contents
Technical Characteristics......................36 Climatic Environment ......................36 Power Supply ........................36 Dimensions..........................36 Installation...........................37 Opening the Chassis ......................37 Install the WLAN antenna......................37 Wall Mounting........................38 Connections ..........................39 Power up.............................40 Appendix A - Console Cable .........................41 Appendix B - RS 232 Interface Cable....................42 ONE100 - Installation Manual... -
Page 5: Safety Instructions
Overcurrent Protection The product requires that the building’s electrical installation is designed for protection against short-circuit (over current) protection. A fuse or circuit breaker no larger than 240 VAC, 10A must be used on the phase conductors. ONE100 - Installation Manual... -
Page 6: Wifi
Only for indoor applications Russian Federation 1.3.2 Geographical restrictions For sefaty reason the userhas to keep his distance to 20 cm from the antenna. 1.3.3 Physical restrictions The user cannot modify any part of the equipment and the antenna. ONE100 - Installation Manual... -
Page 7: Safety Level Interface
Safety Level Interface The daughter board must be installed only in the products authorized by OneAccess and only by qualified personnel as recommended in the installation manual. 1.4.1 LAN Interface 10/100 Mbps (ETHERNET and/or SWITCH) Interface marking on the router back panel: ETHERNET and SWITCH The Ethernet 10/100 Mbps auto-sense has a ’SELV’... - Page 8 These BRI interfaces are TNV-1. The TE mode is not available for Malaysia. The factory configuration of these interfaces is T0, NT mode. Do not connect the interfaces to a public ISDN access, which can damage the product immediately. ONE100 - Installation Manual...
-
Page 9: Directives And Standards
Directives and Standards Declaration of Conformity ONE100 - Installation Manual... -
Page 10: Standards
Standards The ONE100 is designed in conformity with the standards listed hereafter, provided that the basic housing, modules, interface boards and installation kits are mounted as recommended in the corresponding installation manual(s). Safety EN60950-1: 2001, First Safety of information technology equipment, including electrical Edition business equipment. -
Page 11: Fcc Statement (Usa)
Use of a shielded cable is required to comply within Class B limits of Part 15 of FCC Rules. Pursuant to Part 15.21 of the FCC Rules, any changes or modifications to this device not expressly approved by OneAccess may cause, harmful interference and void the FCC authorization to operate this device. ONE100 - Installation Manual... -
Page 12: Router Description
Daughter-Board A daughter-board provides additional ports on the ONE100. Please note that the ONE100 can treat up to 8 simultaneous channels voice. The following ports are provided on the various types of daughter-boards and their markings on router back- panel are indicated in bold between brackets: •... -
Page 13: Front Panel
• 2/4 BRI S0 only in TE. The ONE100 is delivered as a product bundle consisting of a motherboard pre-equipped with its daughter-board. Only a limited number of motherboard/daughter-board combinations is commercialised. For more details, please contact your sales representatives. - Page 14 Not used Interface up Traffic in progress Configured and Malfunction in Voice service operational voice voice service configured, service verification of voice function in progress. No voice Voice Compression communication operational on one or several channels ONE100 - Installation Manual...
-
Page 15: Rear Panel
Rear Panel This section details the various types of ONE100 rear panel so that the user can identify the interface type and port numbering. It should be noted that only the fully- loaded configurations are represented. Other configurations can be derived by not providing some interfaces represented on the product. - Page 16 2 connectors for WLAN antenna, • Input for the external power supply connector (DC input jack, 12V-1, 7A). Figure 3. Rear panel with FXS/FXO/PSTN configuration Depending of the ordered configuration of the system, the rear panel may change. ONE100 - Installation Manual...
- Page 17 • Input for the external power supply connector (DC input jack, 12V-1, 7A). Figure 4. Rear panel with 8 FXS, 1 FXO configuration Depending of the ordered configuration of the system, the rear panel may change. ONE100 - Installation Manual...
- Page 18 • Input for the external power supply connector (DC input jack, 12V-1, 7A). Figure 5. Rear panel with 4 BRI, 2 FXS configuration Depending of the ordered configuration of the system, the rear panel may change. ONE100 - Installation Manual...
- Page 19 2 connectors for WLAN antenna, • Input for the external power supply connector (DC input jack, 12V-1, 7A). Figure 6. Rear panel with FXS/FXO/ISDN Depending of the ordered configuration of the system, the rear panel may change. ONE100 - Installation Manual...
- Page 20 2 connectors for WLAN antenna, • Input for the external power supply connector (DC input jack, 12V-1, 7A). Figure 7. Rear panel with 4 + 4 BRI Depending of the ordered configuration of the system, the rear panel may change. ONE100 - Installation Manual...
-
Page 21: Motherboard
Optional connector for WLAN interface, • The connector intended to receive motherboards, • Jumpers enabling features configuration of interfaces BRI and motherboard. Figure 8. Motherboard Depending on the ordered configuration of the system, the composition of the device may change. ONE100 - Installation Manual... -
Page 22: Configuration Identification
• ADSL annex B and B-DT, • V: FXS interface, • W: WLAN interface. Example: ONE100 4B-2V AEW/a is a ONE100 router equipped with: • 4 ISDN BRI accesses, • 2 FXS, interfaces, • 1 ADSL access Annex A, •... -
Page 23: Interface Description
Auto-negotiation. • Auto MDI/MDX The Ethernet interface of the ONE100 only supports the 100 Mbps full- duplex operations in auto-sense mode. If connected to devices in 10 mbps or half-duplex, the ONE100 interface will not be connected. The problem can appear mostly with devices forced in such mode or with old Ethernet hub. -
Page 24: Console Port (Console)
If the pin 6 is connected to the ground (pin 3), the cable is then identified as a cable connected to an asynchronous terminal. In that case, CTS and RTS can be used. 4.2.3 Cables The console cable is defined in Appendix A. ONE100 - Installation Manual... -
Page 25: Adsl - Adsl 2/2 + - Re-Adsl Interface (Adsl)
ADSL2, (G.992.3) / ADSL 2+ (G.992.5) / RE-ADSL (Reach Extended ADSL, G.992.3 Annex L), • Dying gasp 4.3.2 Connector Pinout RJ11 Connector: Signal RING 4.3.3 Cables The cable of connection to the ADSL must be made using a standard phone cable. ONE100 - Installation Manual... -
Page 26: Ethernet Switch Interface (Switch)
TD (-) RD (-) RD (+) 4.4.4 Cables The cables are shielded, crossover/straight cables with 4 twisted pairs. The switch supports autodetection of crossover/straight cable (’auto-MDI/MDI-X detection’); the transmission pairs are (1-2) and receive pairs are (3-6). ONE100 - Installation Manual... -
Page 27: Pstn Modem Interface (Pstn)
• Compatible with V.32, V.32bis, V.34, V.90 and V.92, • Compliant with TBR21. 4.5.2 Connector Pinout RJ45 Connector: Signal Signal RING 4.5.3 Cables The cable is a standard telephone cord with one twisted pair. ONE100 - Installation Manual... -
Page 28: Rs 232 Interface (V.28)
Each RS 232 interface can be separately configured in DTE or DCE mode when using the synchronous mode: PORT 0 PORT 1 DCE_DTE DCE_DTE DCE_DTE DCE_DTE When using the asynchronous mode, the jumper connection is not relevant. ONE100 - Installation Manual... - Page 29 4.6.4 Cables The cable type must correspond to the desired more (DCE or DTE). All types of cord for RS 232 port are defined in Appendix B. ONE100 - Installation Manual...
-
Page 30: Fxs Analog Interface
The cable used for a connection toward a analog phone is an unshielded cable including 1 twisted pair. The ONE100 with FXS interfaces has got a screw marked located on the rear panel. This must be permanently connected to the main protective earth. -
Page 31: Fxo Analog Interface
The connection of the FXO interfaces is done via RJ45 connectors (1 connector per FXO). 4.8.1 Connector Pinout RJ45 Connector: Signal Signal RING 4.8.2 Cables The cable used for a connection toward a standard analog phone is an unshielded cable including 1 twisted pair. ONE100 - Installation Manual... -
Page 32: S0/T0 Interface
S0/T0 interface The ONE100 supports up to 4 ISDN interface S0/T0. The interfaces can be configured in TE or NT. The connection of the digital voice interface is carried out on the rear panel via RJ45 connectors (1 connector by interface). - Page 33 The WATCHDOG jumper must always be connected so that OneAccess guarantees the correct operation of the ONE100. Description of a block of jumpers for a BRI interface. 100 Ohms Adaptation 100 Ohms Adaptation Receiving Pair Sending Pair Power supply 30 VP...
- Page 34 Configuration with impedance adaptation and with power supply of the terminal: 100 Ohms impedance adaptation connected. The first jumper of the pair is Configuration associated with the transmission, the second one with the reception. Power feeding for ISDN terminal connected. ONE100 - Installation Manual...
- Page 35 TX (+) 4.9.2.2 Daughter board connectors The connection to the BRI accesses is made on the rear panel via RJ-45 connectors. The RJ45 connector pinout is: Signal Signal RX (-) TX (-) TX (+) RX (+) ONE100 - Installation Manual...
-
Page 36: Technical Characteristics
≤ 24g / m3 Absolute Humidity ≤ 2500 m Altitude Power Supply • External Power Supply 200-240 VAC / 20W (12V – 1.7A), Dimensions The dimensions of the housing are: Width 275 mm Height 68 mm Depth 152 mm ONE100 - Installation Manual... -
Page 37: Installation
Chapter 2. Directives and Standard Opening the Chassis Unlock the rear panel screw and removing it. Unclip the lower part of the front panel. Remove the cover. Install the WLAN antenna Please raise it in a vertical position. ONE100 - Installation Manual... -
Page 38: Wall Mounting
Hang the router gently and if necessary adjust the screws in the notches of the router. Figure 10. Positioning of the notches Rear panel of the router Notches Bottom of the router Distance between holes: 244 mm ONE100 - Installation Manual... -
Page 39: Connections
’12V-1.7A’ device connector, • Secure the power supply connection by installing the DC power supply cord into the plastic ring. The device shall not be used with another power supply than a power supply recommended by OneAccess. ONE100 - Installation Manual... -
Page 40: Power Up
The ’STATUS’ LED light remains steady green if software initialization was successful, • The ’STATUS’ LED blinks in case of software absence or error during software loading. Refer to the Software and ONEOS User Guide for more information. ONE100 - Installation Manual... -
Page 41: Appendix A - Console Cable
Appendix A - Console Cable Catalog reference: 4 022 332 B 00 Ed A To PC serial port in terminal mode (Configuration) RJ45 - P1 SIGNAL SUB-D 9 Pts Female - P2 ONE100 - Installation Manual... -
Page 42: Appendix B - Rs 232 Interface Cable
B.1 V.28 / RS 232 DTE Catalog reference: 4022 815 B 00 P2 - - P1 - SIGNAL SUB-D 25 Pts RJ45 Male 115 (RXC) 106 (CTS) 103 (SD) 108 (DTR) 104 (RD) 109 (CD) 105 (RTS) Screening Shield ONE100 - Installation Manual... - Page 43 B-2. V.28 / RS 232 DCE Cable Catalog reference: 9594 508 07146 P2 - - P1 - SIGNAL SUB-D 25 Pts RJ45 female 115 (RXC) 105 (RTS) 104 (RD) 109 (CD) 103 (SD) 108 (DTR) 106 (CTS) Screening Shield ONE100 - Installation Manual...
