ONE180
Installation Manual
Version C
April 2007
http://www.oneaccess-net.com
ONE180 – Installation Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONE180 and is the answer not in the manual?

Questions and answers

Summary of Contents for OneAccess ONE180

  • Page 1 ONE180 Installation Manual Version C April 2007 http://www.oneaccess-net.com ONE180 – Installation Manual...
  • Page 2 OneAccess. OneAccess and the distributors can in no case be held responsible for direct or indirect damage of any kind incurred as a result of any error in the software or guide.
  • Page 3: How To Read This Manual

    This section describes technical characteristics such as operating conditions. Chapter 7 – Directives and Standards This chapter details the list of standards, which the device complies with. Appendix – Connection Description This chapter provides the pin-out of cables that are compatible with the router. ONE180 – Installation Manual...
  • Page 4: Table Of Contents

    T0/S0 Digital Interface (ISDN BRI)......................22 INSTALLATION............................26 Opening the Chassis..........................26 Extension Board ............................27 Connection ...............................28 POWER-UP ..............................29 TECHNICAL CHARACTERISTICS ......................30 Climatic Environment ..........................30 Power Supply ............................30 Dimensions...............................30 DIRECTIVES AND STANDARDS ......................31 Declaration of Conformity ........................31 Standards ..............................32 ANNEXE A: CONSOLE CABLE..........................34 ONE180 – Installation Manual...
  • Page 5: Safety Instructions

    OneAccess and only by qualified staff as recommended in the installation manual. The ONE180 with FXS interfaces has got a screw located on the rear panel. This must be permanently connected to the main protective earth. ONE180 – Installation Manual...
  • Page 6: Directives And Standards

    Directives and Standards Declaration of Conformity ONE180 – Installation Manual...
  • Page 7: Standards

    Standards The ONE180 is designed in conformity with the standards listed hereafter, provided that the basic housing, modules, interface boards and installation kits are mounted as recommended in the corresponding installation manual(s). Safety EN60950-1: 2001, First Safety of information technology equipment, including electrical Edition business equipment.
  • Page 8: Router Description

    Router Description Hardware Description This section details the various types of services offered by the ONE180. The described configurations are the maximum configurations for the motherboard and the extension modules. Other configurations can be derived by under-equipment. Indeed, the ONE180 can have fewer interfaces compared to those presented below.
  • Page 9 This board in its complete configuration has the following interfaces. The interface marking is indicated in bold and between brackets. • 4 ISDN Basic Rate Interfaces S0/T0 configurable TE or NT mode (ISDN BRI). • 4 ISDN Basic Rate Interfaces S0/T0 in TE mode (ISDN BRI). ONE180 – Installation Manual...
  • Page 10: Front Panel

    At least one interfaces are are down IP Interface is not up (example: PPPoA not connected) WLAN Not used Interface up Traffic in progress No auto Auto Auto configurat configuration configuratio successfully n in completed progress ONE180 – Installation Manual...
  • Page 11: Rear Panel

    Rear Panel This section details the various types of ONE180 rear panel so that the user can identify the interface type and port numbering. It should be noted that only the fully-loaded configurations are represented. Other configurations can be derived by not providing some interfaces represented on the product.
  • Page 12 Input for the external power supply connector (DC input jack, 12V-2.2A), • 2 connectors for WLAN antenna. Figure 3. Rear panel with 4 BRI and 2 FXS Depending of the ordered configuration of the system, the rear panel may change. ONE180 – Installation Manual...
  • Page 13 Input for the external power supply connector (DC input jack, 12V-2.2A), • 2 connectors for WLAN antenna. Figure 4. Rear panel with 8 FXS and 1 FXO Depending of the ordered configuration of the system, the rear panel may change. ONE180 – Installation Manual...
  • Page 14 Input for the external power supply connector (DC input jack, 12V-2.2A), • 2 connectors for WLAN antenna. Figure 5. Rear panel with 4 BRI Depending of the ordered configuration of the system, the rear panel may change. ONE180 – Installation Manual...
  • Page 15 Input for the external power supply connector (DC input jack, 12V-2.2A), • 2 connectors for WLAN antenna. Figure 6. Rear panel with 4 + 4 BRI Depending of the ordered configuration of the system, the rear panel may change. ONE180 – Installation Manual...
  • Page 16: Configuration Identification

    D: G.SHDSL access 1 to 2 pairs (2 to 4 wires), • 8: 8 voice communication channels available • W: Wireless LAN Example: ONE180-4B-2V D8 is an ONE180 router equipped with: • 1 access G.SHDSL 2/4 wires, • 4 BRI interfaces •...
  • Page 17: Interface Description

    SHDSL 2 pairs (4 wires): 384 kbps up to 4 640 kbps. 4.1.3 Connector Pinout RJ45 connector: Signal Signal Line 2 Line 1 Line 2 Line 1 4.1.4 Cables For the connection of the G.SHDSHL interface, use the shielded cable that comes with the equipment. ONE180 – Installation Manual...
  • Page 18: Console Interface (Console)

    8 bits, 1 bit for stop, no parity. 4.2.2 Connector Pinout RJ45 connector: Signal Signal • TX: Emission • RX: Reception • NC: Not Connected • GND: Ground 4.2.3 Cable The console cable is defined in Appendix A. ONE180 – Installation Manual...
  • Page 19: Switch Interface (Switch)

    TD (-) RD (-) RD (+) 4.3.5 Cables The cables are shielded, crossover/straight cables with 4 twisted pairs. The switch supports auto detection of crossover/straight cable (’auto-MDI/MDI-X detection’); the transmission pairs are (1-2) and receive (3-6). ONE180 – Installation Manual...
  • Page 20: Fxs Analog Interface (Fxs)

    The cable used for a connection toward an analog phone is an unshielded cable including 1 twisted pair. The ONE180 with FXS interfaces has got a screw marked located on the rear panel. This must be permanently connected to the main protective earth.
  • Page 21: Fxo Analog Interface (Fxo)

    The connection of the FXO interfaces is done via RJ45 connectors (1 connector per FXO). These Interfaces are TNV-3. 4.5.1 Connector Pinout RJ45 Connector: Signal Signal RING 4.5.2 Cables The cable used for a connection toward a standard analog phone is an unshielded cable including 1 twisted pair. ONE180 – Installation Manual...
  • Page 22: T0/S0 Digital Interface (Isdn Bri)

    The ONE180 supports up to 4 ISDN T0/S0 interfaces. The interfaces can be configured in TE or NT. The ONE180 can receive a module that has 2 or 4 digital interfaces. The connection of the digital voice interface is carried out on the rear panel via RJ45 connectors (1 connector per interface).
  • Page 23 The drawing below presents the position of the 4 blocks of 4 jumpers on the daughter card of the configuration ONE180-4B D8 and the WATCHDOG, RESET and JTAG position on the motherboard: Motherboard Motherboard Daughter Card Daughter Card RNIS 0...
  • Page 24 The WATCHDOG jumper must always be connected so that OneAccess guarantees the correct operation of the ONE180. Description of a block of jumpers for a BRI interface: 100 Ohms Adaptation 100 Ohms Adaptation Receiving Pair Sending Pair Power supply 30 VP...
  • Page 25 Configuration with impedance adaptation and with power supply of the terminal: 100 Ohms impedance adaptation connected. The first jumper of the pair is Configuration associated with the transmission, the second one with the reception. Power feeding for ISDN terminal connected. ONE180 – Installation Manual...
  • Page 26: Installation

    EMC standards as defined in Chapter 7. Directives and Standard Opening the Chassis Unlock the 2 screws located on each side of the cover, Remove the cover. ONE180 – Installation Manual...
  • Page 27: Extension Board

    Position the module so that the module metallic faceplate fits in the place made available by the removal of the faceplate, • Lower the module while aligning the module with the motherboard connector, • Plug the module into the motherboard connector, • Screw the fixing stand. ONE180 – Installation Manual...
  • Page 28: Connection

    ’12V-2.2A’ device connector, • Secure the power supply connection by installing the DC power supply cord into the plastic ring. The device shall not be used with another power supply than a power supply provided by OneAccess. ONE180 – Installation Manual...
  • Page 29: Power-Up

    The ’STATUS’ LED light remains steady green if software initialization was successful, • The ’STATUS’ LED blinks in case of software absence or error during software loading. Refer to the Software and ONEOS User Guide for more information. ONE180 – Installation Manual...
  • Page 30: Technical Characteristics

    ≤ 24g / m3 Absolute Humidity ≤ 2500 m Altitude Power Supply • External Power Supply 100-240 VAC / 26,5W (12V – 2,2A), Dimensions The dimensions of the housing are: 320 mm Width Height Depth 200 mm ONE180 – Installation Manual...
  • Page 31: Directives And Standards

    Directives and Standards Declaration of Conformity In progress ONE180 – Installation Manual...
  • Page 32: Standards

    Standards The ONE180 is designed in conformity with the standards listed hereafter, provided that the basic housing, modules, interface boards and installation kits are mounted as recommended in the corresponding installation manual(s). Security EN60950-1:2001 Safety of information technology equipment, including electrical First Edition business equipment.
  • Page 33 The ONE180 respects the European directive on the waste 2002/96/EC disposal from the electric and electronic equipment. Restricted use of Hazardous Substances (RoHS) The ONE180 respects the European directive on the restricted use 2002/95/EC of Hazardous Substances in electric and electronic equipment. ONE180 – Installation Manual...
  • Page 34: Annexe A: Console Cable

    Annexe A: Console Cable Catalog reference: 4 022 332 B 00 Ed A To PC serial port in terminal mode (Configuration) RJ45 - P1 SIGNAL SUB-D 9 Pts Female - P2 ONE180 – Installation Manual...
