One80XM

Installation Guide

Version: 1.0 - 501960
1080 00 T 4025321D00 ind A
6 November 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the One80XM and is the answer not in the manual?

Questions and answers

Summary of Contents for OneAccess One80XM

  • Page 1: Installation Guide

    One80XM Installation Guide Version: 1.0 - 501960 1080 00 T 4025321D00 ind A 6 November 2008...
  • Page 2: Copyright Notice

    OneAccess. OneAccess and the distributors can in no case be held responsible for direct or indirect damage of any kind incurred as a result of any error in the software or guide.
  • Page 3: Table Of Contents

    Dimensions....................... 31 Installing the One80XM ..................32 Opening and Closing the Housing................33 Installing the WLAN Antennas.................. 35 Mounting the One80XM on a Wall ................36 Mounting an Anti-Theft Security Cable..............39 Powering up the One80XM ................40 Annex ....................42 Annex A:Console Cable ..................44...
  • Page 4: Safety Instructions

    Installation Guide Safety Instructions Safety Instructions This chapter gives some important safety instructions to take into account when using and installing the One80XM. The following gives an overview of this chapter: • 1.1 - Safety Information on page 5 •...
  • Page 5: Safety Information

    Connect the power supply to an AC electrical outlet (100-240VAC). Plugging in the power supply turns the router on. • Do not use another type of power supply than the one prescribed by OneAccess. • Over current Protection: This device requires that the building’s electrical installation is designed for protection against short-circuit (over-current) protection.
  • Page 6: Unpacking

    One80XM Chapter 1 Installation Guide Safety Instructions Unpacking Checking the shipping carton Rough handling during shipping causes most early failures. Before installation, check the shipping car- ton for signs of damage: • If the shipping carton is damaged, please place a claim with the carrier company immediately.
  • Page 7: Connection Precautions

    LAN interface ETHERNET/SWITCH RJ45 SELV 1. V.24 2. 10/100 Mbps interface • SELV (Safety Extra Low Voltage): local connection (e.g. PC to One80XM) or leased line inside the building. • TNV-1 (Telecom Network Voltage): telephone line, leased line outside the building.
  • Page 8: Directives And Standards

    One80XM Chapter 2 Installation Guide Directives and Standards Directives and Standards This chapter details the list of standards, which the One80XM complies with. The following gives an over- view of this chapter: • 2.1 - Statements on page 9 •...
  • Page 9: Statements

    Col presente, OneAccess dichiara che questo One80XM è in acquiescenza coi requisiti essenziali e stip- ulazioni attinenti ed altre di Direttivo 1999/5/EC. Με το παρόν η OneAccess δηλώνει ότι το One80XM είναι συµµορφούµενο µε τις βασικές απαιτήσεις και µε τις υπόλοιπες σχετικές διατάξες της οδηγίας 1999/5/EC.
  • Page 10: Environmental Information

    One80XM Chapter 2 Installation Guide Directives and Standards Environmental Information The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end of life. This applies to the device but also to any accessories marked with this symbol.
  • Page 11: Safety Compliance

    One80XM Chapter 2 Installation Guide Directives and Standards Safety Compliance • EN60950-1 - 1st edition: Safety of information technology equipment, including electrical business equipment. • Class 2 equipment. Over-Voltage and Over-Current Protection Compliance The over-voltage and over-current protection complies with ITU-T K.44 and ETSI ETS 300 386-2 recom- mendations.
  • Page 12: Environmental Compliance

    One80XM Chapter 2 Installation Guide Directives and Standards Environmental Compliance • Storage conditions: ETSI ETS 300 019-1-1 Class 1.1. In addition, the storage temperature has to be between -25 and +70°C, with a relative humidity between 0 and 95% non-condensing.
  • Page 13 One80XM Chapter 2 Installation Guide Directives and Standards...
  • Page 14: Router Description

    Chapter 3 Installation Guide Router Description Router Description This chapter describes the One80XM front and rear panels, and the associated technical characteristics. The following gives an overview of this chapter: • 3.1 - What is the One80XM? on page 15 •...
  • Page 15: What Is The One80Xm

    Alternatively this interface can be used for a DMZ zone (De-Militarised Zone) on the customer’s network. With a routing performance of over 20Mbps bidirec- tionally the One80XM can also be used as a full service CPE with Ethernet uplink behind a simple NTU. Full service router...
  • Page 16 Router Description Accelerated Deployment And Service Provision As all ONE products, the One80XM uses the Industry standard Command Line Interface (CLI). This facil- itates the configuration management for the service provider’s technicians and integrates rapidly with automated tools. Several auto discovery and update features make the network rollout straightforward.
  • Page 17: Hardware Description

    The One80XM motherboard is equipped with the following interfaces: • SHDSL line connector • Console port • Managed switch with 4 ports • Additional Ethernet port • WLAN 802.11b/g For more information, refer to 4.1 - Connectors of the One80XM Back Panel on page...
  • Page 18: The Front Panel Led Indicators

    One80XM Chapter 3 Installation Guide Router Description The Front Panel LED Indicators This section gives an overview of the front panel LEDs and what they indicate. The following gives an overview of this section: • 3.3.1 - Introducing the Front Panel LEDs on page 19 •...
  • Page 19 3.3.1 Introducing the Front Panel LEDs When all the connections are made and the One80XM is powered, the LEDs on the front panel reflect the actual status of the device. The following figure shows the front panel LED indicators of the One80XM: LED states One front panel LED can reflect different status modes by the way it lights up.
  • Page 20: Led States

    One80XM Chapter 3 Installation Guide Router Description 3.3.2 LED States The state of the LEDs indicates the following: LED name Colour Description Status Bicolour • OFF: No input power. • ON - green: Switched on and operational. • ON - red: Switched on and not operational.
  • Page 21: Rear View Of The One80Xm

    Installation Guide Router Description Rear view of the One80XM This section describes the One80XM rear panel, so that the user can identify the interface type and port numbering. The following figure shows the back of the One80XM: Following connectors are present:...
  • Page 22: Interface Description

    Installation Guide Interface Description Interface Description This chapter gives an overview of the different connectors on the back of the One80XM. The following gives an overview of this chapter: • 4.1 - Connectors of the One80XM Back Panel on page 23 •...
  • Page 23: Connectors Of The One80Xm Back Panel

    One80XM Chapter 4 Installation Guide Interface Description Connectors of the One80XM Back Panel The following table gives an overview of the possible connectors located at the back of the One80XM and explains their function: Label Function CONSOLE This RJ45 connector is a V.24 DTE interface. This enables you to manage the One80XM locally.
  • Page 24: Shdsl Line Specifications

    One80XM Chapter 4 Installation Guide Interface Description SHDSL Line Specifications • Single pair, dual pair, 4 pair line access • Connector: RJ45 Ω • Impedance: 135 • Cable to be used: 2*2*CAT5E twisted pair • Coding: TCPAM, compliant to ITU-T G.991.2; G.SHDSL, and G.SHDSL.bis via TCPAM-16 and TCPAM-32 •...
  • Page 25: Lan Interface Specifications

    One80XM Chapter 4 Installation Guide Interface Description LAN Interface Specifications • Connector: RJ45 (EIA/TIA 568B) • Cable to be used: standard Ethernet cable (shielded UTP Cat. 5) • Applicable standards: IEEE 802.3 (10Mbps Ethernet), IEEE 802.3u (100Mbps Ethernet) • Speed: 10/100 Mbps auto-sense •...
  • Page 26: Wlan Interface Specifications

    One80XM Chapter 4 Installation Guide Interface Description WLAN Interface Specifications • WIFI version: 802.11b/g • Compliant with the IEEE 802.11-2005 recommendation • maximum data rate: 54 Mbits/second • Operational frequency: 2,4GHz • Default radio channel: 11 • WEP and WPA encryption...
  • Page 27: Port Ethernet Switch Specifications

    One80XM Chapter 4 Installation Guide Interface Description 4 port Ethernet Switch Specifications • Number of ports: 4 • Connectors: RJ45 (EIA/TIA 568B) • Applicable standards: IEEE 802.3 (10Mbps Ethernet), IEEE 802.3u (100Mbps Ethernet) • Characteristics: 10 / 100 Mbps auto-sense...
  • Page 28: Console Port Specifications

    One80XM Chapter 4 Installation Guide Interface Description Console Port Specifications • Connector: RJ45 (EIA/TIA 568B) • Data: RS232 9600 bps 8 data bits no parity 1 stop bit The following table shows the connector layout of the RJ45 Console connector:...
  • Page 29 One80XM Chapter 4 Installation Guide Interface Description...
  • Page 30: Technical Characteristics

    One80XM Chapter 5 Installation Guide Technical Characteristics Technical Characteristics This chapter describes technical characteristics of the One80XM. The following gives an overview of this chapter: • 5.1 - Power Requirements on page 31 • 5.2 - Dimensions on page 31...
  • Page 31: Power Requirements

    Installation Guide Technical Characteristics Power Requirements Power adapter to be used: Switched Power Module 100-240 VAC, 20W, Vout=12 Vdc, Iout=2A. Do not use another type of power supply than the one recommended by OneAccess. Dimensions • Height: 55 mm •...
  • Page 32: Installing The One80Xm

    Chapter 6 Installation Guide Installing the One80XM Installing the One80XM This chapter explains how to install the One80XM. The following gives an overview of this chapter: • 6.1 - Opening and Closing the Housing on page 33 • 6.2 - Installing the WLAN Antennas on page 35 •...
  • Page 33: Opening And Closing The Housing

    Opening and Closing the Housing This section explains how to open and close the housing. Opening the housing To open the housing of the One80XM, proceed as follows: Step Action Disconnect the external power supply; always disconnect the AC input first, then discon- nect the DC input jack on the device itself.
  • Page 34 One80XM Chapter 6 Installation Guide Installing the One80XM Closing the housing To close the housing of the One80XM, proceed as follows: Step Action Slide the cover back over the device. Do not close the housing while holding it upside-down. Fasten both bottom screws.
  • Page 35: Installing The Wlan Antennas

    One80XM Chapter 6 Installation Guide Installing the One80XM Installing the WLAN Antennas The WLAN antennas have been installed in the factory. Raise them in a vertical position. The following figure shows a One80XM with raised antennas:...
  • Page 36: Mounting The One80Xm On A Wall

    Mounting the One80XM on a Wall Procedure The bottom plate of the One80XM has 2 mounting holes in order to enable wall mounting. Refer to the figure below, for the position of these notches. By installing two screws at the required distance, the router can be hung on any vertical surface.
  • Page 37 One80XM Chapter 6 Installation Guide Installing the One80XM Wall mounting...
  • Page 38 One80XM Chapter 6 Installation Guide Installing the One80XM Bottom plate of the One80XM with mounting holes...
  • Page 39: Mounting An Anti-Theft Security Cable

    Mounting an Anti-Theft Security Cable The One80XM has been equipped with two standard Kensington security slots, on both sides of the device, to which a security cable can be attached. The T-bar lock of the security cable provides very effi- cient theft protection by allowing to lock down the One80XM to an anchor point.
  • Page 40: Powering Up The One80Xm

    Connect the power supply to the AC mains (100-240 V AC). Self test A few seconds after the power is switched on, the One80XM performs a series of self-tests and loads the software into memory (RAM), during which the Status LED on the front panel blinks.
  • Page 41 One80XM Chapter 7 Installation Guide Powering up the One80XM...
  • Page 42: Annex

    One80XM Annex Annex...
  • Page 43 One80XM Annex...
  • Page 44: Annex A:console Cable

    One80XM Annex A: Annex Console Cable Annex A: Console Cable The following figure shows the console cable assembly:...
  • Page 45 One80XM Annex A: Annex Console Cable...
  • Page 46: Index

    31 copyright notice 2 powering up the device 40 self test 40 description 14 dimensions of the device 31 Rear view of the OneAccess Router 21 document copyright notice 2 safety environmental information 10 compliance 11 properties 2...
  • Page 47 One80XM Index Index...
