Power up

7
To power up the device, always follow these steps:
•
Connect the DC power input jack from the power supply to the DC power
input of the rear panel of the router,
•
Connect the power supply to the AC mains (200-240 V AC).
Few seconds after power-on, the device performs a series of self-tests and loads
the software into memory (RAM), during which the 'STATUS' LED on the front panel
blinks.
At the end of software loading (about 30 seconds):
•
The 'STATUS' LED light remains steady green if software initialization was
successful,
•
The 'STATUS' LED blinks in case of software absence or error during
software loading.
Refer to the Software and ONEOS User Guide for more information.
