Router Description

3
3.1

Hardware Description

3.1.1 Motherboard Interfaces
The ONE100 motherboard is equipped with the following interfaces. The interface
marking is indicated in bold and between brackets.
•
1 ADSL, ADSL 2/2+, RE-ADSL access (ADSL),
•
1 console port (CONSOLE),
•
1 managed switch with 4 ports (SWITCH),
•
0 to 4 ISDN S0/T0 access, which can be configured in TE or NT mode (ISDN
BRI),
•
2 optional interface WLAN 802.11b/g,
•
1 additional Ethernet port (LAN 100 BT) can be optionally built-in
(ETHERNET).
The addional Ethernet interface of the ONE100 only supports the 100 Mbps
full-duplex operations in auto-sense mode. If connected to devices in 10
mbps or half-duplex, the ONE100 interface will not be connected. The
problem can appear mostly with devices forced in such mode or with old
Ethernet hub.
3.1.2 Daughter-Board
A daughter-board provides additional ports on the ONE100. Please note that the
ONE100 can treat up to 8 simultaneous channels voice. The following ports are
provided on the various types of daughter-boards and their markings on router back-
panel are indicated in bold between brackets:
•
0 to 4 ISDN access S0 in TE (for connection to ISDN public network only)
(ISDN BRI),
•
0 to 8 analog access designed to connect telephone (FXS interface) (FXS),
•
0 to 1 analog access designed to connect telephone line (FXO interface)
(FXO),
•
0 to 1 modem access PSTN (PSTN),
•
0 or 2 V.28 interface.
The addition of a daughter-board enables the installation of one of the following
interfaces:
•
2 FXS,
•
4 FXS,
•
4 FXS, 1 FXO,
•
8 FXS,
•
8 FXS, 1 FXO,
•
4 FXS, 1 FXO, 1 PSTN modem, 2 V.28 interface,
12
ONE100 - Installation Manual
