OneAccess 1424 Installation Manual

Shdsl router
Hide thumbs

Advertisement

Quick Links

Download this manual
1424 SHDSL Router
Installation Guide
Version: 1.8 - 554584
23 January 2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1424 and is the answer not in the manual?

Questions and answers

Related Manuals for OneAccess 1424

Summary of Contents for OneAccess 1424

  • Page 1 1424 SHDSL Router Installation Guide Version: 1.8 - 554584 23 January 2012...
  • Page 2 Modification date 23 January 2012 ©OneAccess Copyright notice The information and descriptions contained in this publication are the property of OneAccess. Such infor- mation and descriptions must not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of OneAccess.
  • Page 3 Hierbij verklaart OneAccess dat deze 1424 SHDSL Router overeenstemt met de essentiële vereisten en andere relevante bepalingen van Richtlijn 1999/5/EC. Par la présente, OneAccess déclare que ce 1424 SHDSL Router est en conformité avec les exigences essentielles et autres articles applicables de la Directive 1999/5/EC.
  • Page 4 Si vous souhaitez plus d'information concernant le point de collecte où vous pouvez apporter vos appareils usagés afin qu'ils soient recyclés, veuillez contacter votre importateur local. Pour la Belgique, vous pouvez prendre contact avec rma@oneaccess-net.com. Das Symbol der durchgestrichenen Abfalltonne auf Rädern bedeutet dass das Produkt in der Europäischen Union einer getrennten Mülsammlung zugeführt werden muss.
  • Page 5 This guide briefly highlights the Total Maintenance Application or All these documents, together with the free maintenance tool TMA and the firmware of the TDRE devices, can be found on the OneAccess Products distribution CD that is delivered with all TDRE prod- ucts.
  • Page 6 This manual contains the following main parts: Part This part … Installation guide shows you how to install and connect the 1424 SHDSL Router. It also explains how to connect to the 1424 SHDSL Router on the pc. Annex gives some additional information.
  • Page 7 Your feedback Your satisfaction about this purchase is an extremely important priority to all of us at OneAccess. Accord- ingly, all electronic, functional and cosmetic aspects of this new unit have been carefully and thoroughly tested and inspected. If any fault is found with this unit or should you have any other quality-related com- ment concerning this delivery, please submit the Quality Comment Form on our web page at www.oneaccess-net.com...
  • Page 8 Safety instructions / Consignes de sécurité ............. 11 Unpacking ........................ 13 Selecting a site ......................14 Mounting the 1424 SHDSL Router on a wall............15 Connection precautions.................... 17 Connecting the 1424 SHDSL Router ............... 18 The front panel LED indicators................. 24 Powering up the 1424 SHDSL Router..............
  • Page 9 1424 SHDSL Router User manual Installation guide...
  • Page 10 Chapter 1 User manual Introducing the 1424 SHDSL Router Introducing the 1424 SHDSL Router This chapter gives an introduction to the 1424 SHDSL Router. The following gives an overview of this chapter: • 1.1 - General description on page 3 •...
  • Page 11 USB interface On some versions of the 1424 SHDSL Router, a USB interface is present. The USB interface is USB 2.0 compliant. It can be used to connect a mobile USB device for backup of the DSL connection over the...
  • Page 12 1424 SHDSL Router Chapter 1 User manual Introducing the 1424 SHDSL Router 1424 SHDSL Router family overview The following gives an overview of the 1424 SHDSL Router versions: 1424 SHDSLbis 1P 64MB 32MB 1424 SHDSLbis 2P 64MB 32MB 1424 SHDSLbis 4P...
  • Page 13 Introducing the 1424 SHDSL Router Maintenance and management tools This section gives a quick overview of the various maintenance and management tools that can be used to manage the 1424 SHDSL Router. The following gives an overview of this section: •...
  • Page 14 Introducing the 1424 SHDSL Router 1.3.1 Overview of various tools The 1424 SHDSL Router is manageable in many different ways. This section gives a quick overview of the various maintenance and management tools. These are: Maintenance or Description and reference...
  • Page 15 The Easy Configurator allows you to add HTML pages on top of the standard Web Interface by adding a set of specific files on the file system of the 1424 SHDSL Router. These files can be made either by OneAccess or by the customer itself.
  • Page 16 1424 SHDSL Router Chapter 1 User manual Introducing the 1424 SHDSL Router 1.3.2 Upgrading the software Some devices are equipped with boot, loader and application software, while others only have boot and application software: • The boot software takes care of the initial phase in the start-up sequence of the device. It is located on the lowest software level.
  • Page 17 Introducing the 1424 SHDSL Router Maintenance and management tools connection possibilities The following table gives an overview of all the maintenance and management tools and how you can connect them with the 1424 SHDSL Router: Maintenance or manage- Tool - 1424 SHDSL Router con-...
  • Page 18 You are advised to read this chapter from the beginning to the end, without skipping any part. By doing so, your 1424 SHDSL Router will be completely installed and ready for configuration when you reach the end of this chapter.
  • Page 19 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router Safety instructions / Consignes de sécurité Information to user Informations envers l'utilisateur • Changes or modifications not expressly • Tout changement ou modification non approved by the party responsible for compli- expressément approuvé...
  • Page 20 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router Over-current Protection Protection contre les surcharges • Do not use another type of power supply than • Ne pas utiliser d'autre type d'adaptateur que the one delivered or prescribed by OneAc- celui livré...
  • Page 21 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router Unpacking Checking the shipping carton Rough handling during shipping causes most early failures. Before installation, check the shipping car- ton for signs of damage: • If the shipping carton is damaged, please place a claim with the carrier company immediately.
  • Page 22 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router Selecting a site Warning Avertissement • Always place the unit in such a way that the air • Placez toujours l'appareil de sorte que les vents are not blocked.
  • Page 23 Mounting the 1424 SHDSL Router on a wall Procedure The bottom plate of the 1424 SHDSL Router has 2 notches in order to enable wall mounting. Refer to the figure below, for the position of these notches. By installing two screws at the required distance, the device can be hung on any vertical surface.
  • Page 24 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router Bottom plate of the 1424 SHDSL Router...
  • Page 25 Take special care not to touch any component or connector on the circuit board. The connectors of the 1424 SHDSL Router should only be connected to the following circuit types: Interface type Interface identification...
  • Page 26 Installing and connecting the 1424 SHDSL Router Connecting the 1424 SHDSL Router This section describes the 1424 SHDSL Router rear panel. It identifies the interface type and port num- bering, and explains how to connect the device. The following gives an overview of this section: •...
  • Page 27 Installing and connecting the 1424 SHDSL Router 2.6.1 Rear view of the 1424 SHDSL Router The following figure shows the back panel of the 1424 SHDSL Router: The following figure shows the back panel of the 1424 SHDSL Router with USB connector:...
  • Page 28 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router Following connectors are present: Interface type Interface identification Type Function Line LINE RJ45 SHDSL line connector Console CONSOLE RJ45 V.24 DTE interface USB interface Ethernet LAN2...
  • Page 29 Installing and connecting the 1424 SHDSL Router 2.6.2 The different parts of the 1424 SHDSL Router The following table gives an overview of the possible connectors located at the back of the 1424 SHDSL Router and explains their function: Interface identi-...
  • Page 30 • It is essential that the earth stud on the back panel is effectively connected to earth. Otherwise, in case of electrical problems, other devices connected to the 1424 SHDSL Router could be damaged. • The hard wired Protective Earth connection must be carried out by authorized service personel.
  • Page 31 2 round M3 washers; these are delivered with the 1424 SHDSL Router. • 1 M3 nut; this is also delivered with the 1424 SHDSL Router. • 1 M3 ring tongue; this is not delivered with the 1424 SHDSL Router. Proceed as follows: Step Action Slide one of the round M3 washers over the clinching stud.
  • Page 32 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router The front panel LED indicators This section gives an overview of the front panel LEDs and what they indicate. The following gives an overview of this section: •...
  • Page 33 2.7.1 Introducing the front panel LEDs When all the connections are made and the 1424 SHDSL Router is powered, the LEDs on the front panel reflect the actual status of the device. The following figure shows the front panel LED indicators of the 1424 SHDSL Router:...
  • Page 34 1424 SHDSL Router Chapter 2 User manual Installing and connecting the 1424 SHDSL Router 2.7.2 LED states The state of the LEDs indicates the following: LED name Colour Description Bicolour • OFF: no input power • ON - Green: switched on and operational •...
  • Page 35 Connect the power supply to the AC mains. Self test A few seconds after the power is switched on, the 1424 SHDSL Router performs a series of self-tests and loads the software into memory (RAM), during which the PWR LED on the front panel blinks.
  • Page 36 User manual DIP switches of the 1424 SHDSL Router DIP switches of the 1424 SHDSL Router This chapter informs about the 1424 SHDSL Router motherboard, and shows how to open the housing. The following gives an overview of this chapter: •...
  • Page 37 • Managed switch with 4 ports • Additional Ethernet port On some versions of the 1424 SHDSL Router, the motherboard is also equipped with: • a USB port No DIP switches have to be set by the user. For more information, refer to...
  • Page 38 DIP switches of the 1424 SHDSL Router Opening and closing the housing Opening the housing To open the housing of the 1424 SHDSL Router, proceed as follows: Step Action Disconnect the external power supply; always disconnect the AC input first, then discon- nect the DC input jack on the device itself.
  • Page 39 Chapter 3 User manual DIP switches of the 1424 SHDSL Router Closing the housing To close the housing of the 1424 SHDSL Router, proceed as follows: Step Action Slide the cover back over the device. Do not close the housing while holding it upside-down.
  • Page 40 TMA sub-system picture TMA sub-system picture The sub-system picture is a TMA tool that visualises the status information of the 1424 SHDSL Router. This chapter explains how to display the sub-system picture, and how to interpret the visual indications. How to display the sub-system picture?
  • Page 41 1424 SHDSL Router Chapter 4 User manual TMA sub-system picture Below, the 1424 SHDSL Router sub-system picture is displayed:...
  • Page 42 1424 SHDSL Router Chapter 5 User manual Technical specifications Technical specifications This chapter gives the technical specifications of the 1424 SHDSL Router. The following gives an over- view of this chapter: • 5.1 - SHDSL line specifications on page 35 •...
  • Page 43 1424 SHDSL Router Chapter 5 User manual Technical specifications SHDSL line specifications • Single pair, dual pair, 4 pair line access • Connector: RJ45 Ω • Impedance: 135 • Cable to be used: 2*2*CAT5E twisted pair, min. No. 26 AWG.
  • Page 44 1424 SHDSL Router Chapter 5 User manual Technical specifications Cable Lay-out • RJ45-RJ45 SHDSL cable with label 4028 761 A00: Cable/Modular Plug Specification Type Cable : UTP Cat 5E AWG24 Stranded Color: Violet Modular Plug RJ45 8Pos. 8Contacts Unshielded Modular Plug RJ45 8Pos. 8Contacts Unshielded Color : Transparent Plating:Gold Min.
  • Page 45 1424 SHDSL Router Chapter 5 User manual Technical specifications LAN1 4 port Ethernet switch specifications • Number of ports: 4 • Connectors: RJ45 (EIA/TIA 568B) • Cable to be used: standard Ethernet cable, minimum category 5 • Applicable standards: IEEE 802.3 (10Mbps Ethernet), IEEE 802.3u (100Mbps Ethernet) •...
  • Page 46 1424 SHDSL Router Chapter 5 User manual Technical specifications LAN2 interface specifications • Connector: RJ45 (EIA/TIA 568B) • Cable to be used: standard Ethernet cable, minimum category 5 • Applicable standards: IEEE 802.3 (10Mbps Ethernet) IEEE 802.3u (100Mbps Ethernet) IEEE 802.1ag (OAM on Ethernet interface) ITU-T Y.1731 (OAM on Ethernet interface)
  • Page 47 1424 SHDSL Router Chapter 5 User manual Technical specifications USB interface specifications • Standard Type A USB connector. • USB version 2.0 interface. • The USB interface can operate as a master. • The USB master interface can deliver up to 500mA at 5V.
  • Page 48 1424 SHDSL Router Chapter 5 User manual Technical specifications Console port specifications • Connector: RJ45 (EIA/TIA 568B) • Data: RS232 9600 bps 8 data bits no parity 1 stop bit • The following table shows the connector layout of the RJ45 Console connector:...
  • Page 49 1424 SHDSL Router Chapter 5 User manual Technical specifications Memory specifications • Flash memory: 32 MB • RAM: 64 MB...
  • Page 50 Power adapter to be used: Switched Power Module AC in, 50/60 Hz, Vout=12 Vdc; Iout=1A for devices without USB interface; Iout=1,5A for devices with USB interface. Note that a 24/48VDC power adapter can also be delivered. Do not use another type of power supply than the one recommended by OneAccess.
  • Page 51 1424 SHDSL Router Chapter 5 User manual Technical specifications Dimensions The standard version of the 1424 SHDSL Router has a metal housing with the following characteristics: • Width: 275 mm • Height: 55 mm • Depth: 146 mm • Weight: 1,26 kg Alternatively, a plastic housing may be offered with the following characteristics: •...
  • Page 52 1424 SHDSL Router Chapter 5 User manual Technical specifications Safety compliance • EN60950-1: Safety of information technology equipment, including electrical business equipment. • Class II equipment. 5.10 Over-voltage and over-current protection compliance The over-voltage and over-current protection complies with ITU-T K.44 and ETSI EN 300 386 recom- mendations.
  • Page 53 1424 SHDSL Router Chapter 5 User manual Technical specifications 5.12 Environmental compliance • Storage conditions: ETSI ETS 300 019-1-1 Class 1.1. In addition, the storage temperature has to be between -25 to +70°C, with a relative humidity between 0 and 95% non-condensing.
  • Page 54 1424 SHDSL Router Annex Annex...
  • Page 55 1424 SHDSL Router Annex A: Annex Console cable Annex A: Console cable Standard console cable The following figure shows the console cable assembly; it has reference code 501288:...
