Oil drain plug
Oil discharge port
Oil level check bolt
Filler plug
Maintenance
Changing
1. Prepare a suitable container to drain oil.
2. Remove oil drain plug and drain oil from crankcase.
Hot oil can cause burns.
Properly dispose of drained oil.
3. Replace oil drain plug.
4. Remove oil gauge and fill the specified oil into the oil
filler.
7.4.2

Transmission Oil

Inspecting
1. Park machine on a horizontal surface.
2. Remove the oil level check bolt and see if oil level is at
the bolt hole. (oil comes out of the hole.) If oil level is
low, add oil.
Amount of oil :
(Up to a point where oil reaches oil level
check hole )
Adding
1. Remove filler plug.
2. Fill the specified oil into the filler.
Oil to use :
– 33 –
CAUTION
N O T E
page 30
page 30
7
