2.2.6 RTFM Switch

When the Intercom is operational and linked to the network, use the Reset Test Function
Management (RTFM) switch (see SW1 in
confirm the Intercom's IP Address and test that the audio is working.
Note

2.2.6.1 Announcing the IP Address

To announce a speaker's current IP address:
1. Press and release the RTFM switch (SW1) within a five second window.
Note
Note
Operations Guide
You must do this test prior to final assembly.
The speaker will use DHCP to obtain the new IP address (DHCP-assigned address or
default to 10.10.10.10 if a DHCP server is not present).
Pressing and holding the RTFM switch for longer than five seconds will restore the speaker
to the factory default settings.
930323A
Installing the VoIP Indoor Intercom with Keypad
Figure 2-11) on the Intercom board to announce and
Figure 2-11. RTFM Switch
Parts List
RTFM
