2. On the Network Configuration page, enter values for the parameters indicated in
Web Page Item
Stored Network Settings
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
Current Network Settings
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
3. After changing the parameters, click Save Settings. This updates the changed parameters and
reboots the Intercom if appropriate.
4. Connect the Intercom to the target network.
5. From a system on the same network as the Intercom, open a browser with the new IP address of
the Intercom.
Operations Guide
Table 2-9. Network Configuration Parameters
Description
Shows the settings stored in non-volatile memory.
Select either DHCP IP Addressing or Static IP Addressing by
marking the appropriate radio button. If you select Static, configure
the remaining parameters indicated in
go to Step 3.
Enter the Static IP address.
Enter the Subnet Mask address.
Enter the Default Gateway address.
Enter the DNS Server 1 address.
Enter the DNS Server 2 address.
Shows the current network settings.
Shows the current Static IP address.
Shows the current Subnet Mask address.
Shows the current Default Gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930323A
Installing the VoIP Indoor Intercom with Keypad
Table 2-9 . If you select DHCP,
