Operations Guide
Figure 2-7. Connector Locations
Table 2-3. Connector Functions
Function
LED Interface
Microphone Interface
Speaker Interface
Keypad Interface
930323A
Installing the VoIP Indoor Intercom with Keypad
CyberData Corporation
10
