2. On the Sensor Configuration page, enter values for the parameters indicated in
Web Page Item
Door Sensor Settings
Door Sensor Normally Closed
Door Open Timeout (in seconds)
Flash Button LED*
Activate Relay
Play Audio Locally
Play Audio Remotely
Dial Out Extension
Intrusion Sensor Settings
Flash Button LED*
Activate Relay
Play Audio Locally
Play Audio Remotely
Dial Out Extension
3. After changing the parameters, click Save Settings.
Operations Guide
Table 2-14. Sensor Configuration Parameters
Description
Select the inactive state of the door sensors.
Select the number of seconds that you want to pass before
the door sensor is activated.
Check this box to flash the LED until the sensor is
deactivated (roughly 10 times/second).
Check this box to activate the relay until the sensor is
deactivated.
Check this box to loop an audio file out of the Intercom
speaker until the sensor is deactivated.
Check this box to call a preset extension and play a pre-
recorded audio file (once).
Enter the desired dial-out extension number. For
information about dial-out extension strings and DTMF
tones, see
DTMF Tones (using
Use this button to test the door sensor.
Check this box to flash the LED until the sensor is
deactivated (roughly 10 times/second).
Check this box to activate the relay until the sensor is
deactivated.
Check this box to loop an audio file out of the Intercom
speaker until the sensor is deactivated.
Check this box to call a preset extension and play a pre-
recorded audio file (once).
Enter the desired dial-out extension number. For
information about dial-out extension strings and DTMF
tones, see
DTMF Tones (using
Use this button to test the Intrusion sensor.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930323A
Installing the VoIP Indoor Intercom with Keypad
Section 2.3.6.1, "Dial Out Extension Strings and
rfc2833)".
Section 2.3.6.1, "Dial Out Extension Strings and
rfc2833)".
CyberData Corporation
39
