Web Page Item
Speed Dial Timeout (in seconds)
Keypad (0 through 9, *, and #)
ID
Call Button
ID
Security Dial Mode
Enable Security Keypad Operation
Relay Activation Timeout (in seconds)
Operations Guide
Table 2-11. Button Configuration Parameters (continued)
Description
Type the desired time (in seconds) that you want a button
held before it will initiate a call.
Note: A Speed Dial Timeout setting of 0 will start a call
as soon as the button is released.
Enter the desired dial-out extension number (64 character
limit).
Note: For information about dial-out extension strings and
DTMF tones, see
Strings and DTMF Tones (using
Type the desired Extension ID (64 character limit).
Enter the desired dial-out extension number (64 character
limit).
Note: For information about dial-out extension strings and
DTMF tones, see
Strings and DTMF Tones (using
Type the desired Extension ID (64 character limit).
Select Enable Security Keypad Operation to put the
Intercom into Security Dial Mode. In Security Dial Mode,
the Intercom will act like a normal, one-button Intercom by
calling the extension specified in the Call Button field.
When a security code is entered on the keypad that
matches one of the seven-digit fields specified on the
page, the relay will be activated.
• This mode is meant for installation with security doors. In
Security Dial Mode, the Intercom will act like a normal,
one-button Intercom by calling the extension specified in
the Call Button field.
• Up to 10 (7-digit maximum) security codes can be
registered with the device. When one of these codes is
typed on the keypad (followed by the # key), it will activate
the relay for the Relay Activation Timeout (in seconds)
setting.
• It is possible to enter a security code both inside and out
of calls.
• In this mode normal relay operation is suspended and
the following settings are non-operational:
Relay On Button Press,
Relay During Call Active
Relay During Ring
Relay During Night-ring
• In this mode, you can't send dtmf to a remote extension
using the keypad. You can however setup delayed dtmf
tones in the dial out string.
Type the desired length of time (in seconds) that you want
the relay to remain activated after a security code is
entered.
930323A
Installing the VoIP Indoor Intercom with Keypad
Section 2.3.6.1, "Dial Out Extension
rfc2833)".
Section 2.3.6.1, "Dial Out Extension
rfc2833)".
