4 . 1 6 . 3 A R P C a c h
4 . 1 6 . 3 A R P C a c h
Click Diagnostics and click ARP Cache Table to view the content of the ARP (Address
Resolution Protocol) cache held in the router. The table shows a mapping between an Ethernet
hardware address (MAC Address) and an IP address.
Each item is explained as follows:
Item
Clear
Refresh
4 . 1 6 . 4 D H C P T a b
4 . 1 6 . 4 D H C P T a b
The facility provides information on IP address assignments. This information is helpful in
diagnosing network problems, such as IP address conflicts, etc.
Click Diagnostics and click DHCP Table to open the web page.
Available settings are explained as follows:
Item
Index
e T a b l e
e T a b l e
Description
Click it to clear the whole table.
Click it to reload the page.
l e
l e
Description
It displays the connection item number.
331 Vigor3200 Series User's Guide
