2 . 3 . 1 . 4 D H C P
2 . 3 . 1 . 4 D H C P
1. Choose WAN1/WAN2/WAN3/WAN4 as the WAN Interface and click the Next button.
The following page will be open for you to specify Internet Access Type.
2. Click DHCP as the protocol. Type in all the information that your ISP provides for this
protocol.
Available settings are explained as follows:
Item
Host Name
MAC
Back
Next
Description
Type the name of the host.
Some Cable service providers specify a specific MAC
address for access authentication. In such cases you need to
enter the MAC address.
Click it to return to previous setting page.
Click it to get into th/e next setting page.
23 Vigor3200 Series User's Guide
