Each item is explained as follows:
Item
Index
Service Name
Protocol
Public Port
Private IP
Status
Press any number under Index to access into next page for configuring port redirection.
Available settings are explained as follows:
Item
Enable
Mode
Service Name
Protocol
WAN Interface
Public Port
Vigor3200 Series User's Guide
Description
Display the number of the profile.
Display the description of the specific network service.
Display the transport layer protocol (TCP or UDP).
Display the port number which will be redirected to the
specified Private IP and Port of the internal host.
Display the IP address of the internal host providing the
service.
Display if the profile is enabled (v) or not (x).
Description
Check this box to enable such port redirection setting.
Two options (Single and Range) are provided here for you to
choose. To set a range for the specific service, select Range. In
Range mode, if the public port (start port and end port) and the
starting IP of private IP had been entered, the system will
calculate and display the ending IP of private IP automatically.
Enter the description of the specific network service.
Select the transport layer protocol (TCP or UDP).
Select the WAN interface used for port redirection.
Specify which port can be redirected to the specified Private
IP and Port of the internal host. If you choose Range as the
port redirection mode, you will see two boxes on this field.
Simply type the required number on the first box. The second
one will be assigned automatically later.
140
