WDS – Wireless Distribution Service
For every coverage gap, use the following procedure:
1 Identify the position of the gap filler AP (or APs), taking into consideration the availability of a
parent (see below). Only consider using two or more hops if the coverage gap cannot be filled with
APs that are only one WDS hop away from the wired infrastructure.
2 Identify the preferred and back-up parents for every gap filler AP. Take into consideration the
following factors:
The parents must be close enough to the gap filler so as to guarantee max PHY rate.
●
It is better if every gap filler has a different parent.
●
3 Identify the channels to be used by every WDS link. Investigate alternatives to avoid overloading a
single channel:
Keep neighboring WDS trees on different (non-overlapping) channels.
●
If you are using more than one WDS hop, try switching between radios every hop.
●
4 Then do the following:
Create a WDS WM-AD for each coverage gap (it is also possible to configure a single WDS WM-
●
AD for all gap fillers but it is may be less flexible in the future).
