Using the Menu Bar and the Toolbar

File Handles file input/output, such as opening and saving.
Edit Performs simple actions on selected objects, such as cutting and pasting.
Sew Allows you to control the way the pattern will be sewn.
Display Modifies the appearance of the screen.
Option Allows you to start the other applications and to set the Design Page size
and unit system.
Stage Allows you to move from one stage to the next or previous one.
Help Gives you access to the on-screen help information system.
Many functions available on the menu can also be accessed by clicking an icon on the Toolbar or by
pressing a shortcut key or key combination.
When you leave the cursor for a while on a button of the Toolbar, a label indicating the function of the but-
ton displays.

File Menu

The menu handles file input/output, such as opening, saving and printing.
File

New

Open

Save

Save As

Import Figure

Exit

68
Creates a new blank Design Page and switches to Stage 2.
Opens a previously saved file (*.bmp files open in stage 1,
*.pel files open in stage 2, *.pem files open in stage 3 or
4). You can open *.pel and *.pem files created with Version
1.0 of this software.
Saves your Design Page on the disk as a Version 2.0 file
(default). To read this file with Version 1.0, select the File
Type Version 1.0.
Saves the current file under a new file name.
Adds a *.pem file to your Design Page (available only in
Stage 3).
Exits the application.
page 68
page 73
page 77
page 82
page 84
page 86
page 90
page 69
page 69
page 70
page 70
page 71
page 72
