Installing the NAC-3355/3395 Appliance Into the Slide Rails

Step 1 Extend the slide rails forward out of the four-post rack until they click (twice) into place.
Step 2 Carefully lift the NAC-3355/3395 and tilt it into position over the slide rails so that the rear chassis nail
heads on the CAM/CAS line up with the rear slots on the slide rails (see
Step 3 Slide the CAM/CAS down so that the rear chassis nail heads slip into the two rear slots, and then slowly
lower the front of the CAM/CAS until the other chassis nail heads slip into their respective slots on the
slide rails.
Ensure that the front latch slides over the chassis nail heads.
Note
Figure 2-15
OL-20326-01
Fasten Rear of Slide Rail to Four-Post Rack
Step 8 and Step 9 to attach the other slide rail to the selected rack space for your
Position the NAC-3355/3395 In the Slide Rails
2
3
1
Rack-Mounting Your Cisco NAC Appliance CAM/CAS
4
5
Cisco NAC Appliance Hardware Installation Guide
Figure 2-15).
