Rack-Mounting Your Cisco NAC Appliance CAM/CAS
Figure 2-12
Fasten the front of the slide rail and EIA latch to the front of the four-post rack by installing a screw in
Step 8
the bottom hole of the selected rack space for your NAC-3355/3395. Then, install another screw in the
middle hole to secure the front of the slide rail to the four-post rack (see
Use the 12-24 screws that came in the rack installation kit if you have installed clip nuts or cage nuts in
Note
the four-post rack mounting rails.
Figure 2-13
Step 9 Use two screws to fasten the rear of the slide rail to the respective rear mounting rail of the four-post
rack in the upper and bottom holes of the selected rack space for your NAC-3355/3395 (see
Cisco NAC Appliance Hardware Installation Guide
2-24
Set Up Slide Rails
Post D
Post C
Post B
Post A
Fasten Front of Slide Rail to Four-Post Rack
Slots
Chapter 2 Preparing for Installation
Figure 2-13).
Figure 2-14).
